REPLIGEN XCell ATF Series

XCell
TM
ATF System with C410:V4B Controller User Guide
82
Input Page 2
Profibus Address
Tagname plc in DB31
PLC Address
Definition
Units
Data type
Byte #
Bit #
Structure
Tagname in structure
0
0
InputPageX
PB_ATF_START_STOP
%DB31.DBX128.0
AFT 1=Start/0=Stop
Byte
1
InputPageX
PB_ATF_Ack_Alarms
%DB31.DBX128.1
ATF Acknowledge Alarms
2
InputPageX
PB_Reset_Counters
%DB31.DBX128.2
Algorithm Performance Counters - Reset
3
InputPageX
PB_ATF_Control_Mode
%DB31.DBX128.3
Control Mode
4
InputPageX
PB_ATF_Slope_Enabled
%DB31.DBX128.4
Slope Function Enabled
5
6
7
1
0
InputPageX
RequestedDataPage
%DB31.DBW130
Requested Data Page
Int-16
2
0
3
0
InputPageX
SendingDataPage
%DB31.DBW132
Sending Data Page
Int-16
4
0
5
InputPage2
EFLOWMINSP
%DB31.DBD252
Min Exhaust Flow Setpoint
LPM
Real
6
7
8
9
InputPage2
PTIMEMAXSP
%DB31.DBD256
Max Pressure Flow Setpoint
SEC
Real
10
11
12
13
InputPage2
PTIMEMINSP
%DB31.DBD260
Min Pressure Flow Setpoint
SEC
Real
14
15
16
17
InputPage2
ETIMEMAXSP
%DB31.DBD264
Max Exhaust Flow Setpoint
SEC
Real
18
19
20
21
InputPage2
ETIMEMINSP
%DB31.DBD268
Min Exhaust Flow Setpoint
SEC
Real
22
23
24
25
InputPage2
PV1MAX
%DB31.DBD272
Flow Proportional Valve Max Value
%
Real
26
27
28
29
InputPage2
PV1MIN
%DB31.DBD276
Flow Proportional Valve Min Value
%
Real
30
31
32
33
InputPage2
PV2MAX
%DB31.DBD280
Exhaust Proportional Valve Max Value
%
Real
34
35
36
37
InputPage2
PV2MIN
%DB31.DBD284
Exhaust Proportional Valve Min Value
%
Real
38
39
40
41
InputPage2
PRV1MAX
%DB31.DBD288
Pressure Regulator Maximum Value
BAR/PSI
Real
42
43
44
45
InputPage2
PRV1MIN
%DB31.DBD292
Pressure Regulator Minimum Value
BAR/PSI
Real
46
47
48
49
InputPage2
PRV2MAX
%DB31.DBD296
Exhaust Regulator Maximum Value
BAR/PSI
Real
50
51
52
53
InputPage2
PRV2MIN
%DB31.DBD300
Exhaust Regulator Minimum Value
BAR/PSI
Real
54
55
56
57..63
Unused
