XCell
TM
ATF System with C410:V4B Controller User Guide
28
The main screen displays the parameters in the following tables:
Displays current Date and Time
Field entries by Administrator (or, if authorized, by Engineer) through the
Main screen: P-FLOW SP, E- FLOW SP, PV1, PRV1, PV2, PRV2
Displays current P-Flow Set Point (SP) (LPM)
When running, displays pump Flow rate Process Value (PV) of last pump
cycle (LPM)
Displays current P-Flow Calculated cycle time (Sec)
When running, displays Actual pump flow cycle Time of last pump cycle
(Sec)
Displays current E-Flow Set Point (SP) (LPM)
When running, displays pump exhaust Flow rate Process Value (PV) of last
pump cycle (LPM)
Displays current E-Flow Calculated cycle time (Sec)
When running, displays Actual pump exhaust cycle Time of last pump cycle
(Sec)
Displays current position Set Point of Flow Proportional Valve (0-100%)
Displays current position Set Point of Exhaust Proportional Valve (0-100%)
Displays current setting of automatic pressure regulator (0 to 35psi)
Displays current setting of automatic exhaust regulator (-15 to 0 psi)
Displays current pressure between controller and Diaphragm Pump (PSI)
Displays current controller status:
PUMP OFF
INFLATING
EXHAUSTING
PUMP WARNING
PUMP ALARM
SYSTEM STOP
Indicates Controller PLC is ON and in RUN mode
Indicates Diaphragm Pump is in RUN mode
Indicates Controller OFF/ON Status
Indicates Flow Direction Solenoid is OFF/ON
Connected Bioreactor ID (input in setup basic)
Batch ID information (input in Batch Info)
Time the current batch has been running (reset in Batch Info)
Displayed username of current login
