ATF System with C410:V4B Controller User Guide
78
2) Pneumatic devices are set to produce a minimum setting. (PV2=100%, PRV2=-5.00 PSI,
Solenoid=0 [vacuum])
a. While “SendingDataPage” is still equal to 3…
b. Set InputPage3.PV2_SP = 100 Confirmed by examining OutputPage2.PV2
c. Set InputPage3.PRV2_SP = -5 Confirmed by examining
OutputPage1.PRV2
d. Reset InputPage3.Force_Solenoid = 0 Confirmed by examining
OutputPage4.Solenoid_Forced
e. The pressure in the system approaches the minimum value commanded.
Pressure gauge reading is allowed to stabilize.
Note: OutputPage0.P2_PV and OutputPage0.PRV2_PV should be within ±0.5 PSIG of the value on the
external pressure gauge.
3) Pressure gauge reading is provided to the controller.
a. Programmer provides a data entry location for technician to enter the pressure
value.
b. While “SendingDataPage” is still equal to 3…
c. Set InputPage3. P2_P1_EU = the pressure value from the data entry location.
d. Set InputPage3.P2_P1_Capture = 1 until the OutputPage4.P2_P1_Caputured bit
is received.
i. Wait for the “RequestedDataPage” to be equal to 4; since cycling through
output data pages is recommended.
ii. Examine OutputPage4.P2_ P1_Capture. When true…
e. Reset InputPage3.P2_P1_Capture = 0; the minimum capture bit is momentarily
asserted.
4) Pneumatic devices are set to produce a maximum setting. (PV1=100%, PRV1=20.00 PSI,
Solenoid=1 [pressure or air])
a. While “SendingDataPage” is still equal to 3…
b. Set InputPage3.PV1_SP = 100 Confirmed by examining OutputPage1.PV1
c. Set InputPage3.PRV1_SP = 20 Confirmed by examining
OutputPage1.PRV1
d. Set InputPage3.Force_Solenoid = 1 Confirmed by examining
Outputpage4.Solenoid_Forced
e. The pressure in the system approaches the maximum value commanded.
Pressure gauge reading is allowed to stabilize.
Note: OutputPage0.P2_PV and OutputPage0.PRV1_PV should be within ±0.5 PSIG of the value on the
external pressure gauge.
5) Pressure gauge reading is provided to the controller.
a. Programmer provides another data entry location for technician to enter the
pressure value.
b. While “SendingDataPage” is still equal to 3…
c. Set InputPage3. P2_P2_EU = the pressure value from the data entry location.
