Resol DeltaSol BX User Manual

en
61
InstallationIndications, functions and optionsMessages Commissioning Operation and function
13
Starting time delay
If the starting delay option is activated, a starting time for the thermal disinfection
with starting delay can be adjusted. The activation of the backup heating is then
delayed until that starting time after the monitoring period has ended.
If the monitoring period ends, for example, at 12:00 o'clock, and the starting time
has been set to 18:00, the reference relay will be energised with a delay of 6 hours
at 18:00 instead of 12:00 o'clock.
Note:
If the thermal disinfection option is activated, the display channels TDIS,
CDIS, SDIS and DDIS will be displayed.
SDIS
Starting time delay
Adjustment range: 00:00 … 23:00
Factory setting:
18:00 (full hours only)
RDIS
Relay thermal disinfection
Adjustment range 2, 3, 4
Factory setting: 3
TDIS
Disinfection temperature
Adjustment range: 0 … 95 °C
in steps of 1 °C
Factory setting: 60 °C
OSDIS
Starting delay option
Selection: ON / OFF
Factory setting: OFF
TSDIS
Sensor thermal disinfection
Adjustment range 2, 3, 4, 5
Factory setting: 3
15
OPARR 14
PUSH
PARRE
Parallel relay option
Adjustment range: 2, 3, 4
Factory setting: system-dependent
OPARR
Parallel relay option
Selection: ON / OFF
Factory setting: OFF
INVER
Inversion
Selection: ON / OFF
Factory setting: OFF
14
14
Parallel relay
With this function, e. g. a valve can be controlled in parallel to the pump via a
separate relay.
If solar loading takes place (R1 and/or R2) or if a solar function is active, the relay
selected will be energised. The parallel relay can also be energised inversely.
Note:
If R1 and/or R2 are in the manual mode, the selected parallel relay will
not be energised.
13
