Resol DeltaSol E Manual

sensor denomination
Tcol temperature collector
Tcol2 temperature collector 2
Tstb temperature tank 1 bottom
Tst2b temperature tank 2 bottom
Tst3b temperature tank 3 bottom
Tst4b temperature tank 4 bottom
T-HE temperature heat exchanger
Tby temperature bypass
HSE temperature protection against legionnaires‘
disease
Th 1-10 temperature thermostat 1 to 10
T1 DT5-9 temperature DT5 to 9 high
T2 DT5-9 temperature DT5 to 9 low
T1 AH-HC temperature backup heating-heating circuit
T2 AH-HC temperature backup heating-heating circuit
HC T-FL temperature heating circuit flow
HC T-outd. temperature heating circuit outdoors
HC RTA11 heating circuit remote control
T1 WMZ temperature flow heat quantity measurement
T2 WMZ temperature return heat quantity measurement
WMZ flowmeter
Digital input message input
Abbreviations - sensors
sensor location
1 DeltaSol E
2 DeltaSol E
3 DeltaSol E
4 DeltaSol E
5 DeltaSol E
6 DeltaSol E
7 DeltaSol E
8 DeltaSol E
9 DeltaSol E
10 DeltaSol E
11 Flow HC
12 1. HCM (S1)
13 1. HCM (S2)
14 1. HCM (S3)
15 1. HCM (S4)
16 1. HCM (S5)
sensor location
17 1. HCM (S6)
18 Flow 1. HCM
19 2. HCM (S1)
20 2. HCM (S2)
21 2. HCM (S3)
22 2. HCM (S4)
23 2. HCM (S5)
24 2. HCM (S6)
25 Flow 2. HCM
26 3. HCM (S1)
27 3. HCM (S2)
28 3. HCM (S3)
29 3. HCM (S4)
30 3. HCM (S5)
31 3. HCM (S6)
32 Flow 3. HCM
Sensor allocation
Sensors 1-10 are the sensors connected to the controller.
Sensors 12-32 are the sensors connected to the additionally
connected heating circuit modules.
Sensors 11, 17, 25 and 32 show the calculated flow set
temperatures.
Abbreviations - relay
relay denomination
pump col. 1 (2) solar pump collector field 1to 2
Solar pump St 1-4 solar pump tank 1 to 4
2 PV St 1-4 2-port valve tank 1 to 4
3 PV St 1-3 3-port valve tank 1 to 3
func. bl. 1-5 function block 1-5
HSE protection against legionnaires‘ disease
bypass bypass-circuit
cooling func. cooling function
tank load. tank loading
par. relay parallel relay
ext. HE external heat exchanger
message rel. message relay
AH suppress. backup heating suppression
HC backup heat. heating circuit backup heating
HC pump heating circuit pump
HC Mi open heating circuit mixing valve open
HC Mi closed heating circuit mixing valve closed
3.5 Overview of relay and sensor allocation
D e lt a S o l
®
E
© RESOL 10306_DeltaSol_E.monus.indd
15 |
