VBus
®
/PWM interface adapter
The VBus
®
/PWM interface adapter is used for the speed control of a pump via a PWM
or 0-10 V signal. Via the VBus
®
the adapter receives information from the controller about
speed. The speed is converted into a PWM or direct voltage signal and put out to the
corresponding terminals.
RESOL VBus
®
/PWM interface adapter Article no.: 180 008 60
AM1 Alarm module
The AM1 alarm module is designed to signal system failures. It is to be connected to the
VBus
®
of the controller and issues an optical signal via a red LED if a failure has occurred.
The AM1 also has a dry contact relay output, which can e. g. be connected to a building
management system (BMS). Thus, a collective error message can be issued in the case of a
system failure.
RESOL AM1 Alarm module Article no.: 180 008 77

Resol DeltaSol E Specifications

General

Brand	Resol
Model	DeltaSol E
Category	Controller
Language	English
