USER MANUAL CUTTER Q1
RESQTEC Manual Q1 CUTTER (DM068K06)
5. SPECIFICATIONS
5.1. TECHNICAL SPECIFICATIONS
5.1.1 SI-SYSTEM DATA
5.1.2 IMPERIAL SYSTEM DATA
Q1 CUTTER NEO1-COUPLER STD-COUPLER
Nominal pressure 350 bar
Hose safety factor 8:1 (2,800 bar)
Dimensionscutterheadexcl.exiblecover(LxWxH) 339 x 59 x 178 mm
Dimensions control unit (L x W x H) 225 x 104 x 232 mm
Operational weight (cutter head + remote control) 7.7 kg (4.6 kg + 3.1 kg) 7.6 kg (4.6 kg + 3.0 kg)
Max. cutting opening 60 mm
Reach 73 mm
Max. cutting force 208 kN / 21.2 tons
Max. spreading opening 83 mm
Max. spreading force 40.6 kN / 4.1 tons
Cutting head Rotatable 180 degrees
EN 13204 AC60-B-7.7
EN 13204 cutting capability 1C 2D 3C 4- 5- (B-class)
NFPA 1936 cutting capability A4 B4 C3 D3 E3
Q1 CUTTER NEO1-COUPLER STD-COUPLER
Nominal pressure 5,075 PSI
Hose safety factor 8:1 (40,600 PSI)
Dimensionscutterheadexcl.exiblecover(LxWxH) 13 3/8’’ x 2 3/8’’ x 7’’
Dimensions control unit (L x W x H) 8 7/8’’ x 4 1/8’’ x 9 1/8’’
Operational weight (cutter head + remote control) 17.0 lbs (10.1 lbs + 6.9 lbs) 16.8 lbs (10.1 lbs + 6.7 lbs)
Max. cutting opening 2 1/4’’
Reach 2 7/8’’
Max. cutting force 208 kN / 46,760 lbs
Max. spreading opening 3 1/4’’
Max. spreading force 40.6 kN / 9,127 lbs
Cutting head Rotatable 180 degrees
EN 13204 AC60-B-7.7
EN 13204 cutting capability 1C 2D 3C 4- 5- (B-class)
NFPA 1936 cutting capability A4 B4 C3 D3 E3
