RESQTEC Manual Q1 CUTTER (DM068K06)
5.1.3. CUTTING CAPABILITIES
Resqtec

cutting
tools
are

designed

and

manufactured
in

accordance

with
EN-

and

NFPA-certications

and
 classications.
The

following

tables

represent

the

EN-

and

NFPA-classication

system:

Categorizing according to EN13204 – SI-system
Categorizing according to NFPA1936 – Imperial system
CATEGORY
LETTER
ROUND HOT
ROLLED BAR
FLAT SHEET METAL TUBE
SQUARE
HOLLOW TUBE
RECTANGULAR
HOLLOW TUBE
mm mm mm mm mm
A Ø 14 30 x 5 Ø 21.3 x 2.3
B Ø 16 40 x 5 Ø 26.4 x 2.3
C Ø 18 50 x 5 Ø 33.7 x 2.6 35 x 4
D Ø 20 60 x 5 Ø 42.6 x 2.6 40 x 4 50 x 25 x 2.5
E Ø 22 80 x 8 Ø 48.3 x 2.9 45 x 4 50 x 30 x 3.0
F Ø 24 80 x 10 Ø 60.3 x 2.9 50 x 4 60 x 40 x 3.0
G Ø 26 100 x 10 Ø 76.1 x 3.2 55 x 4 80 x 40 x 3.0
H Ø 28 110 x 10 Ø 76.1 x 4.0 60 x 4 80 x 40 x 4.0
I Ø 32 120 x 10 88.9 x 4.0 60 x 5 80 x 40 x 5.0
J Ø 36 130 x 10 88.9 x 5.0 70 x 4 100 x 50 x 4.0
K Ø 40 140 x 10 101.6 x 4.0 70 x 5 100 x 50 x 5.0
CATEGORY
LETTER
ROUND HOT
ROLLED BAR
FLAT SHEET METAL TUBE
SQUARE
HOLLOW TUBE
ANGLE IRON
Inch Inch Inch Inch inch
1 Ø 3/8 1/4 x 1/2 3/8 0.68 x 0.09 1/2 x 0.06 1/2 x 1/8
2 Ø 1/2 1/4 x 1 3/4 1.05 x 0.11 1 3/4 x 0.06 1 x 1/8
3 Ø 5/8 1/4 x 2 1 1.32 x 0.13 1 x 0.08 1 1/4 x 3/16
4 Ø 3/4 1/4 x 3 1 1/4 1.66 x 0.14 1 1/4 x 0.12 1 1/2 x 3/16
5 Ø 7/8 1/4 x 4 1 1/2 1.90 x 0.15 1 1/2 x 0.12 1 1/2 x 1/4
6 Ø 1 3/8 x 3 2 2.38 x 0.15 1 3/4 x 0.12 1 3/4 x 1/4
7 Ø 1 1/4 3/8 x 4 2 1/2 2.88 x 0.20 2 x 0.15 1 1/2 x 3/8
8 Ø 1 1/2 3/8 x 5 3 3.50 x 0.22 2 1/2 x 0.19 2 x 3/8
9 Ø 1 3/4 3/8 x 6 3 1/2 4.00 x 0.23 3 x 0.19 2 1/2 x 3/8
