USER MANUAL CUTTER Q1
RESQTEC Manual Q1 CUTTER (DM068K06)
2. PRODUCT SUMMARY
2.1. INTRODUCTION
07
Thank
you
for
choosing
Resqtec.
We
are
condent
that
we
live
up
to
your
expectations.
This
manual
has
been
compiled
carefully
to
supply
the
reader with all the necessary information. Read all the instructions before using the product to assure safe and optimal use of the product. The
se
instructions contain aspects relevant to safe and optimal use of the product.
The product has been manufactured by Resqtec Zumro. For addresses, please refer to the last page of this manual or to our internet site at
www.resqtec.com
.
2.2. PRODUCT DESCRIPTION
The
Q1
has
been
designed
and
engineered
to
assist
reghters,
USAR-teams
and
other
rescue
workers
with
the
various
rescue
applications
they
encounter.
We
are
condent
that
the
design
of
this
product
will
enable
those
working
in
these
environments
to
not
only
negotiate
the
obstacles
they encounter, but to perform their work more safely.
The Q1 is a double-acting hydraulic product designed to be driven by a Resqtec hydraulic pump. It is a very compact cutter, which can be
operated by one or two persons. Its blades can rotate 180° to enable reaching places which are impossible to reach with conventional cutters.
The
Q1
operates
with
hydraulic
oil
and
350
bar/5,075
PSI
allowable
pressure.
To
see
which
specic
hydraulic
uid
your
product
uses,
see
chapter
1.4
of
this
manual,
or
look
on
the
product
label.
Further
information
regarding
the
hydraulic
uid
in
your
system
can
be
found
in
the
“Material
Safety
Data
Sheet”
or
“MSDS”
which
came
with
your
product.
2.3. COMPONENT IDENTIFICATION
180° ROTATIONAL BLADES
PROTECTION COVER
POSITIONING HANDLE
PROTECTED HOSES
CONTROL HANDLE
NEO1 (MALE) COUPLER
