Retsch PM400 - Overview Table of the Parts of the Device

Operating the machine
24
5.2 Overview table of the parts of the device
Element
Description
Function
A
Cover
Closes the grinding chamber
B
Damper for cover
Secures the cover when it is open
H
Clamping unit for grinding chamber
Clamps grinding jar on the support
I
Grinding jar
Sample vessel
J
Turntable
Support for the grinding jar plate
K
Pin closing mechanism
Safety lock for the cover
L
Control panel
Device controller
M
Closing mechanism
Support for pin closing mechanism
N
Handle for clamping unit (lead frame)
Handle to clamp the grinding jars
N1
Locking sleeve
Prevents the twist grip from being turned accidentally
O
Safety Slider
Safety component – checking whether the clamping
unit is inserted and clamped
P
Display window
Displays the safety function
Q
Latching bracket
Supports the clamping unit
S
Main switch
Disconnects the device from the mains
T
IEC socket
Power supply for the power cable
U
Serial interface
Interface for communication with the device
V
Support for safety fuse
Access to the device fuse
W
Type plate
Description of device parameters
X
Warning sign to pull out the plug
Warning of electric shock
Y
Sign with instruction to read the
operating manual
Sign pointing out the need to read the operating
manual
