Operating the machine
29
Fig.
: Clamping bolt
When grinding with 2 grinding jars these must be inserted so they are opposite
each other. The two remaining empty grinding stations must each be secured by a
clamping bolt (Sb) and a clamping unit.
Otherwise the safety slider function will stop the device from starting.
Strong oscillation of the machine indicates poor weight balance or incorrectly
clamped grinding jars!
Fig.
: Clamping bolt activates the Safety Slider
• When using two grinding jars, place a clamping bolt and a clamping unit in
the two empty opposite grinding stations.
