Rexel 1150 S2 - Model 1150 S2 and 1250 S2 Cutting Head

Deskside and Office 230vissue7 11 01/02/02
ILLUSTRATED PARTS MANUALS
SERIES 7 SHREDDERS – 230v
DESKSIDE AND OFFICE MODELS
MODEL 1150 S2 AND 1250 S2 CUTTING HEAD
No Description Part 1150 S2 1250 S2 Comments
1 Side Frame (Motor) D53567 1
1 Side Frame (Motor) D53571 1
2 Pin, 20MM long, 5mm dia PEG77 2 2
3 1-1 Gear D53530 2 2
4 Circlip, 17mm ID TRU88 1 1
5 Lost Motion Collar D53790 1 1
6 Spur Gear Assembly A53650 1 1
7 Gearbox Spacer D53520 1 1
8Dowel Pin PEG91 6 6
9 End Closing Plate D53065 1 1
10 Bolt, M5 x 70 MM SCM151 5 5
11 Ball bearing BR23 5 5
12 Ball bearing BR28 2 2
13 Compound Gear Assembly A53547 1
13 Compound Gear Assembly A53547 1
14 Screw, M5 x 12 CSK Nyloc SCM152 2 2
15 Screw, M5 x 10 SCM9 4 4
16 Lockwasher, M5 SHK10 4 4
17 Lock nut, M5 NM16 2 2
18 Torsion Spring (Motor side) D53524 1 1
Torsion Spring (Bearing Side) D53525 1 1 Not Shown
19 Trigger Arm D53523 2 2
20 Bolt, M5 x 30 SCM140 2 2
21 Motor, 550W SL20-307 1
21 Motor, 150W SL20-301 1
22 Screw, M6 x 12 SCM15 6 8
23 Lockwasher, ¼” SHK4 14 16
24 Tie Bar (Top Motor) D53636 1 1
26 Motor fan Supplied with motor
27 Grommet, Blind SL18-140 3 3
28 Cover Brace D53648 1 1
29 Active Safety Flap A53583 1 1
30 Bin Full Flap D53731 1 1
31 Grommet SL18-333 2 2
32 Location Plate D53554 2 2
33 Side Frame (Bearing) D53594 1
33 Side Frame (Bearing) D53611 1
34 Grommet GRM22 1 1
35 Snap Bush SL18-369 2 2
36 Pop Rivet RTS68 4 4
37 Nut, M6 NM5 8 8
38 Washer, ¼” Plain PLN4 8 8
39 Vibration Isolator SL18-305 4 4
