Deskside and Office 230vissue7 12 01/02/02
ILLUSTRATED PARTS MANUALS
SERIES 7 SHREDDERS – 230v
DESKSIDE AND OFFICE MODELS
No Description Part 1150
S2
1250
S2
Comments
40 Nut Cover SL18-325 2 2
41 Cutter Shaft – Driven D53561 1 1
42 Tie Bar D53573 2 2
43 Key, 5X5X16 KEY32 2 2
44 Stripper plate – front D53556 1 1
45 Deflector Tab D53641 2 2
46 Stripper Plate – Rear D53555 1 1
47 Cutter Shaft – Drive D53562 1 1
48 Key ‘Woodruff’ 5x9x22 KEY33 1 1
END PLATE ASSEMBLY A53526SP 1 1 Comprises 9,11,12
GEARBOX SPACER ASSEMBLY A53531SP 1 1 Comprises 7,8
SIDE FRAME ASSEMBLY (MOTOR) A53584SP 1 Comprises 1,11,32
SIDE FRAME ASSEMBLY (BRG) A53585SP 1 Comprises 33,32,10
SIDE FRAME ASSEMBLY (MOTOR) A53595SP 1 Comprises 1,11,32
SIDE FRAME ASSEMBLY (BRG) A53596SP 1 Comprises 33,32,10
HEAD ASSEMBLY A53627SP 1 Comprises all except
21,25,26,34,35,14
HEAD ASSEMBLY A53629SP 1 Comprises all except
21,25,26,34,35,14
SHREDDER OIL, 500ML 40100 1 1
