Rexel 1150 S2 - Model 1150 S3, 1250 S3 and S4 Cutting Head

Deskside and Office 230vissue7 14 01/02/02
ILLUSTRATED PARTS MANUALS
SERIES 7 SHREDDERS – 230v
DESKSIDE AND OFFICE MODELS
MODEL 1150 S3, 1250 S3 and S4 CUTTING HEAD
No Description Part 1150 S3 1250 S3 1250 S4 Comments
1 Side Frame (Motor) D53685 1
1 Side Frame (Motor) D53686 1 1
2 Pin, 20MM long, 5MM dia PEG77 2 2 2
3 1:1 Gear D53515 2 2 2
4 Circlip, 17MM ID TRU88 1 1 1
5 Lost Motion Collar D53790 1 1 1
6 Spur Gear Assembly A53650 1 1 1
7 Gearbox Spacer D53520 1 1 1
8Dowel Pin PEG91666
9 End Closing Plate D53065 1 1 1
10 Bolt, M5 x 70 SCM151 5 5 5
11 Ball Bearing BR23 5 5 5
12 Ball Bearing BR28 2 2 2
13 Compound Gear Assembly A53547 1 1 1
14 Screw, M5 x 12 CSK Nyloc SCM152 2 2 2
15 Screw, M5 x 10 SCM9 4 4 4
16 Lockwasher, M5 SHK10 4 4 4
17 Locknut, M5 NM16 2 2 2
18 Torsion Spring (Motor Side) D53524 1 1 1
Torsion Spring (Bearing
Side)
D53525111Not Shown
19 Trigger Arm D53523 2 2 2
20 Bolt, M5 x 30 SCM140 2 2 2
20
A
Tie Bar D53573 1 1 1
21 Motor, 550W SL20-307 1 1
21 Motor, 150W SL20-301 1
22 Bolt, M6 x 12 SCM15 9 9 9
23 Lockwasher ¼” SHK4 20 20 20
24 Tie Bar (Top Motor) D53636 1 1 1
26 Motor fan Supplied with motor
27 Grommet SL18-333 2 2 2
28 Grommet, Blind SL18-140 3 3 3
29 Cover Bracing plate D53648 1 1 1
30 Active Safety Flap A53583 1 1 1
31 Bin Full Flap D53588 1 1 1
32 Infeed Chute – Rear D53680 1 1 1
33 Location plate D53682 2 2 2
34 Side Frame (Bearing) D53684 1
34 Side Frame (Bearing) D53687 1 1
35 Grommet GRM22 1 1 1
