Rexel 1150 S2 - Page 16

Deskside and Office 230vissue7 15 01/02/02
ILLUSTRATED PARTS MANUALS
SERIES 7 SHREDDERS – 230v
DESKSIDE AND OFFICE MODELS
No Description Part 1150
S3
1250
S3
1250
S4
Comments
36 Snap Bush SL18-369 2 2 2
37 Pop Rivet RTS68 4 4 4
38 Nut M6 NM5 8 8 8
39 Washer, plain PLN4 8 8 8
40 Vibration Isolator SL18-305 4 4 4
41 Nut Cover SL18-325 2 2 2
42 Infeed chute – Front A53693 1 1 1
43 Tie (stripper) bar D53679 2 2 2
44 Stripper D53678 144 144 150
45 Screw, M6 CSK Skt Head SCM104 3 3 3
46 Cutter Shaft – Driven D53557 1
46 Cutter Shaft – Driven D53559 1 1
47 Key KEY32 2 2 2
48 Deflector Tab D53641 2 2 2
49 Cutter Shaft – Drive D53558 1
49 Cutter Shaft – Drive D53560 1 1
50 Key KEY33 1 1 1
51 Paper Chute D53708 1 1 1 Not Shown
END PLATE ASS. A53526SP 1 1 1 Comprises 9,11,12
GEARBOX SPACER ASS. A53531SP 1 1 1 Comprises 7,8
SIDE FRAME ASS. (MOTOR) A53691SP 1 Comprises 1,11,33
SIDE FRAME ASS. (BEARING) A53692SP 1 Comprises 11,33,34
SIDE FRAME ASS (MOTOR) A53689SP 1 1 Comprises 1,11,33
SIDE FRAME ASS (BEARING) A53690SP 1 1 Comprises 11,33,34
HEAD ASSEMBLY A53628SP 1 Comprises all except
21,25,26,35,36,14
HEAD ASSEMBLY A53630SP 1 Comprises all except
21,25,26,35,36
HEAD ASSEMBLY A53631SP 1 Comprises all except
21,25,26,35,36
SHREDDER OIL, 500ML 40100
