Deskside and Office 230vissue7 17 01/02/02
ILLUSTRATED PARTS MANUALS
SERIES 7 SHREDDERS – 230v
DESKSIDE AND OFFICE MODELS
MODEL 1250 S5 CUTTING HEAD
No Description Part Qty Comments
1 Side Frame (Motor) D53768 1
2 Oilite Bush BSH60 2
3 Spigot Shaft D53652 1
4Grooved Pin PM2 1
5 Circlip, 17MM ID TRU88 1
6 1:1 Gear D53530 2
7 Lost Motion Collar D53790 1
8 Spur Gear Assembly A53650 1
9 Gearbox Spacer D53520 1
10 Dowel Pin PEG91 6
11 End Closing Plate D53721 1
12 Bolt, M5 x 70 SCM151 5
13 Bearing BR23 5
14 Ball Bearing BR28 2
15 Compound Gear Assembly A53547 1
16 Screw, M5 x 12 CSK Nyloc SCM152 2
17 Screw M5 x 10 SCM9 4
18 Lockwasher M5 SHK10 4
19 Locknut, M5 NM16 2
20 Torsion Spring (Motor Side) D53524 1
Torsion Spring (Bearing Side) D53525 1
21 Trigger Arm D53523 2
22 Bolt, M5 x 30 SCM140 2
23 Tie Bar D53573 1
24 Motor 550W SL20-307 1
25 Bolt M6 x 12 SCM15 6
26 Lockwasher ¼” SHK4 12
27 Tie Bar (Top Motor) D53636 1
29 Motor fan
30 Grommet SL18-333 2
31 Grommet, Blind SL18-140 3
32 Cover Brace D53648 1
33 Active Safety Flap A53583 1
34 Bin Full Flap D53784 1
35 Infeed Guide Chute (Rear) D53680 1
36 Cutter Shaft – Drive D53753 1
37 Location Plate D53767 2
39 Side Frame (Bearing) D53769 1
40 Snap Bush SL18-369 2
41 Pop Rivet RTS68 4
42 Nut M6 NM5 8
