Deskside and Office 230vissue7 18 01/02/02
ILLUSTRATED PARTS MANUALS
SERIES 7 SHREDDERS – 230v
DESKSIDE AND OFFICE MODELS
No Description Part Qty Comments
43 Washer plain PLN4 8
44 Vibration Isolator SL18-305 4
45 Nut Cover SL18-325 2
46 Stripper D53723 169
46 Stripper D53785 169
47 1/32” Spacer (Hex) D53812 344
48 Cutter (Ground) D53750 169
48 Cutter (Knurled) D53751 169
49 Infeed Guide Chute (Front) A53693 1
50 Stripper Bar D53572 2
51 Screw, M6 x 16 CSK Skt Head SCM104 2
52 Cutter Shaft – Driven D53754 1
53 Key 5X5X16 KEY32 2
54 Collar D53755 2
55 Locknut 9076BI 4
56 Deflector Tab D53725 2
57 Key 5x9x22mm KEY33 1
58 Pin, 20MM Long, 5MM dia PEG77 2
GEARBOX SPACER ASS. A53531SP 1
SIDE FRAME ASS. (MOTOR) A53770SP 1
SIDE FRAME ASS. (BEARING) A53771SP 1
END PLATE ASS. A53722SP 1
HEAD ASS. A53783SP 1
To Next Page
