Rexel 1150 S2 - Models 250 Electrics

Deskside and Office 230v
26
26/05/99
ILLUSTRATED PARTS MANUALS
SERIES 7 SHREDDERS – 230v
DESKSIDE AND OFFICE MODELS
MODELS 250 ELECTRICS
Description Part S2S3S4 S5Comment
Capacitor 12 µfd
SL6-41 1 For motor start
Capacitor 15 µfd
SL6-53 1 1 For motor start
Capacitor 10 µfd
SL6-40 1 For motor start
Cord Set Europe SL4-90 1 1 1 1
Cord Set UK SL4-88 1 1 1 1
Fuse 10A SL15-22 1 1 1 For Inlet Socket
Fuse 5A SL15-21 1
Screw Brass 2BA SCR686B 1 1 1 1 Earth Stud
Locknut Brass 2 Ba NUT42B 2 2 2 2 For earth stud
Lockwasher 2Ba SHK3 2 2 2 2 For earth stud
Washer Plain brass 2Ba PLN3B 2 2 2 2 For earth stud
Mains Inlet Socket, Fused SL12-51 1 1 1 1
Microswitch SL8-167 1 1 1 Bin full switch
Microswitch SL8-165 2 2 2 Door Switch
Spares use A53548SP
Microswitch Insulation D53545 1 1 1 For bin full switch
Nut, M3 Nyloc NM14 2 4 4 4 Bin full switch + sensors
PCB Assembly including Auto
Start sensors
SL17-305111 1
Screw, M3x8 Pozi Pan Plasform SCR713 7 7 7 7 To Fix PCB Assembly
Screw, M3 x 16 Pozi Pan head SCM78 4 4 4 Limit switches
Screw, M3 x 16 Pozi Pan head SCM78 2 2 2 Bin Full switch
Washer, M3 plain PLN31 2 6 6 6 For limit switches and sensors
Washer, M3 plain PLN31 4 4 4 Bin Full switch + sensors
Wiring Loom A54222 1 1 1 Main Loom
Wiring Loom A53822 1 1 1 Safety Circuit loom
Wiring Loom A53152 1 Main Loom
Wiring Loom D53760 1 1 1 1 Earth Wire
Wiring Loom D53762 1 1 1 1 General Interconnection
Wiring Loom D53776 1 1 1 General Interconnection
Motor SL20-284 1
Motor SL20-301 1
Motor SL20-303 1 1
