ILLUSTRATED PARTS MANUALS
SERIES 7 SHREDDERS – 230v
DESKSIDE AND OFFICE MODELS
MODELS 1150 ELECTRICS
Description Part S2S3Comments
Capacitor 12 µFD
SL6-41 1 1 For motor start
Cord Set Europe SL4-90 1 1
Cord Set UK SL4-88 1 1
Fuse 10A SL15-2211For inlet socket
Inlet Socket Fused SL12-51 1 1
Screw Brass 2Ba SCR686B 1 1 Earth stud
Locknut, Brass Nut42B 2 2 For earth stud
Lockwasher SHK3 2 2 For earth stud
Washer Brass 2 Ba Plain PLN3B 2 2 For earth stud
Micro switch SL8-16711Bin full switch
Microswitch SL8-16522Door switch
Spares use A53548SP
Microswitch SL8-16411Safety Flap only
Microswitch Insulation D53545 1 1 For Bin Full Switch
Nut M3 Nyloc NM14 6 6 Limit switches + sensors
PCB assembly with Auto start sensors SL17-305 1 1
Screw M3 x 16 SCM78 4 4 Limit switches
Screw M3 x 8 Pozi pan plasform SCR713 7 7 To fix PCB assembly
Washer M3 plain PLN31 6 6 Limit switches + sensors
Wiring Loom A54222 1 1 For limit switches
Wiring Loom A53835 1 1 For limit switches
Wiring Loom D53776 1 1 General Interconnections
Wiring Loom D53760 1 1 General Interconnections
Motor SL20-301 1 1
