ILLUSTRATED PARTS MANUALS
SERIES 7 SHREDDERS – 230v
DESKSIDE AND OFFICE MODELS
MODELS 1250 ELECTRICS
Description Part S2S3S4S5Comments
Capacitor 30 µFD
SL6-57 1111For motor start (plastic cased)
Capacitor 30 µFD
SL6-60 1111For motor start (metal cased alternative) see issue 7
Cord Set Europe SL4-90 1111
Cord set UK SL4-88 1111
Fuse 10A SL15-22 1111For inlet socket
Inlet Socket, Fused SL12-51 1111
Screw Brass 2Ba SCR686 1111Earth stud
Locknut, Brass NUT42B 2222For earth stud
Lockwasher SHK3 2222For earth stud
Washer, Brass 2Ba PlainPLN3B 2222For earth stud
Choke SL17-310` 1111For SL17-304 PCB – To s/n A664703
Microswitch SL8-167 1111Bin full switch
Microswitch SL8-147 1 Security only
Microswitch SL8-165 2222Door Switch
Microswitch SL8-164 1111Safety Flap
Microswitch Insualtion D53545 1111For Bin Full Switch
Nut M3 Nyloc NM14 6668Limit switch and sensors
Display Power PCB
Assembly
SL17-304 1111Fastened to top cover
Screw M3 x 16 SCM78 4446Limit switches
Screw M3 x 8 Pozi Pan SCR713 7777To fix display PCB
Washer M3 Plain PLN31 6668Limit switches and sensors
Wiring Loom A54222 1111Main Loom
Wiring Loom A53822 1111Safety Circuit Loom
Auto Start Sensors SL17-280 1111
Wiring Loom D53748 2 Security Sinter
Wiring Loom D53760 1111Earth Wire
Wiring Loom D53776 1111General Interconnections
Motor SL20-307 1111
