ILLUSTRATED PARTS MANUAL
LM35, LM45 LAMINATORS
Rexel Business Machines, Westbank, Droitwich Spa, Worcestershire. WR9 9AP England
Tel: +44 (0) 1905 771555 Fax: +44 (0) 1905 823374
3
MOULDINGS
NO PART DESCRIPTION 35 45 COMMENT
1 D50543 Top Ellipse Rexel 1 1
2 D50539 Bottom Ellipse 1 1 Made from D50501
3 D50502 Entry Moulding 1 1
4 D50555 Entry Moulding With Printing 1 1
5 D50504 Main Front Shelf 1 1
6 D50505 Main Lid 1 1
7 D50506 Paper Support 1 1
8 D50507 Keypad Cover 1 1
9 D50508 Pcb Cover Plate 1 1
10 D000332 Keypad Decal - 1
11 D000349 LM35 Model No. Decal 1 - NOT SHOWN
11 D000350 LM45 Model No. Decal - 1 NOT SHOWN
12 SL18-294 Rubber Feet 4 4
13 SCR714 M4 X 12 Plasform Pan Head Screw 4 4
14 SCR713 M3 X 8 Plasform Pan Head Screw 2 3
15 D50589 Lcd Cover 1 -
18 D50578 Fixing Bracket - 1
19 D50579 Paper Deflector Blade - 1
21 PLN31 Plain Washer - 1
22 A50594 MAIN LID COMPLETE 1 1 COMPRISES 6, 7
24 D000185 Service Call Decal 1 1
25 RPLM35 Rating Decal 1 - NOT SHOWN
25 RPLM45 Rating Decal - 1
27 D000368 Carrier Warning Decal 1 - NOT SHOWN.
A50575 MAIN LID ASSEMBLY 1 1 COMPRISES 5, 6, 7, 8
