ILLUSTRATED PARTS MANUAL
LM35, LM45 LAMINATORS
Rexel Business Machines, Westbank, Droitwich Spa, Worcestershire. WR9 9AP England
Tel: +44 (0) 1905 771555 Fax: +44 (0) 1905 823374
7
ELECTRICS
NO PART DESCRIPTION 35 45 COMMENT
1 D50535 Switch Blanking Plate 1 1
2 D50511 Keypad 1 -
2 D50519 Keypad - 1
3 A50620 LM35/45 Heater Assembly 1 1 NOT SHOWN comprising
15-19, 22-25 plus heads 5-
9, 21,22.
4 SL17-508 Control Pcb 1 -
4 SL17-309 Control Pcb - 1
5 SL20-267 Motor 1 -
5 SL20-268 Motor - 1
6 SL4-102 Cordset 1 1 UK ONLY
7 PLN31 M3 Plain Flat Standard Washer 2 2
8 NM14 Nyloc Nut M3 X 0.5 2 2
9 SL18-310 Nylon Spacers 2 2
10 SCM115 M3 X 20 C’sunk P/Pan Drive Screw 2 2
11 SL13-87 Crimp Terminal Housing 2-Way 1 1
12 SL13-90 Crimp Terminal Housing 4-Way 1 -
13 SL13-91 Crimp Terminal Housing 3-Way - 1 NOT SHOWN
14 SL13-88 Crimp Terminal Housing 2-way - 1 NOT SHOWN
15 M3 Plain Washer Brass 3 3
16 M3 X 12 C’sunk Slot Head Brass 2 2
17 M3 Full Nut Brass 3 3
18 M3 Shakeproof Washer Ext 2 2
19 Wiring Assembly 1 1
20 NOT USED
21 SCR713 M3 X 8 Self Tap Screw 2 2
22 Butt Connector 2 2
23 Top Heater Element (With Fuse) 1 1
24 Bottom Heater Element (with fuse) 1 1
25 Thermistor Assembly 1 1 NOT SHOWN
26 NOT USED
27 D50581 Microswitch Actuator Arm - 1
28 D50525 Microswitch Assembly - 1 NOT SHOWN
30 SL13-86 Crimp Terminal - 2 NOT SHOWN
31 SL13-85 Crimp Terminal 2 2 NOT SHOWN
