Rexel LM45 - Heads

ILLUSTRATED PARTS MANUAL
LM35, LM45 LAMINATORS
Rexel Business Machines, Westbank, Droitwich Spa, Worcestershire. WR9 9AP England
Tel: +44 (0) 1905 771555 Fax: +44 (0) 1905 823374
5
HEADS
NO PART DESCRIPTION 35 45 COMMENT
1 A50607 Driven Roller Shaft Assembly 3 2
2 BR 27 Ball Bearing 8 8
3 D50599 Roller Gear 4 4
4 TRU 66 10mm Circlip 4 4
5 Insulating Blanket 2 2
5A A50620 LM35/45 Heater Assembly 1 1
Comprises 5-9, 21,22, plus electrics 15-19,
22-25
6 Heater Compression Spring 8 8
7 Heater Backing Plate 2 2
8 Bottom Heater Extrusion 1 1
9 Top Heater Extrusion 1 1
10 D50598 Sideframe 2 2
11 D50601 Side Frame Pin 4 4
12 D50514 Idler Gear 1 1
13 D50515 Idler Gear Pin 1 1
14 TRU 91 8mm Push On Fastener 1 1
15 D50612 Extension Spring (Front) 4 4
16 D50600 Extension Spring (Rear) 4 4
18 D50597 Lever Arm 4 4
19 A50615 Driven Roller Assembly (Steel) - 1
20 A50605 Drive Roller Shaft Assembly 1 -
20 A50617 Drive Roller Shaft Assembly - 1
21 Pressure Bar Support Clip 3 3
22 Blanket Retaining Clips 5mm 12 12
23 D50591 Top Backing Plate (2mm) - -
Not used on LM35, replaced with Pressure
Bar
24 D50608 Pressure Bar 1 1
25 TRU 85 Grip Washer - 2
A50622 SPARES HEAD ASSEMBLY 1 -
Comprises 1 - 18, 20, 22, 25 plus Electrics
15 - 17, 23, 24 + earth
A50623 SPARES HEAD ASSEMBLY - 1
Comprises 1 - 25 plus Electrics 15 - 17, 23,
24+ earth
