Rexing S1 Pro - Camera Overview; Visual Features

Camera Overview
I. Visual Features
6
1. Menu/Mode Button
2. Record/Up Button
3. Power Button
4. Down/Toggle Button
5. OK Button
6. Power Cord Connection Port
7. Rearview Camera Connection Port
8. Reset Pinhole
GPS
Socket
USB 5V
Socket
Smart
Hardwire
Kit Socket
Rearview
Camera
Socket
IR light
Cabin Camera
Front Camera
6 7
8
1
2
3 4 5
Note:
GPS is an optional feature, needs to connect to the included GPS Logger. The S1 Pro does not
support memory expansion.
