PAGE 29
MICROPHONE OPERATIONS
Using convenient microphone keypad to operate desired frequency/
channel through the RMP-05 Mic keys
• Keypad Lock
Pull down the slider switch to lock keypad for overriding keypad en-
try, The lamp is turned off and all of keypads is not work except PTT
switch.
• Function Shortcut On Keypad
Moni button : forced monitor this channel or frequency.
Power button: switch tx power to HI/MIDDLE/LOW level.
Bandwidth button: switch bandwidth to 12.5K/20K/25KHz.
V/M button : Toggle VFO to frequency with channel mode
button : Transmit selected signaling (DTMF,2-Tone,5-Tone)
Down Key
PTT key
Keypad
Keypad lock
Up Key
Microphone
