6 HYDRAULIC VALVE CONFIGURATION
The left side of screen is used to set up the valve configuration.
6.1 Valves
When * is in front of CONVEYOR, press Enter to select the valves. Choose valves to edit among conveyor,
spinner,
or Prewet.
6.2 Mode
Conveyor has five modes: close loop (auto), open loop, manual 12V triggered, manual speed or manual.
Spinner can only work under manual mode.
Prewet has seven modes: off, open, V-Flow, slave (Return Oil to Pre-wet), manual speed, manual and manual
12V.
Deice has four modes: off, manual, open and 1 BOOM.
* CONVEYOR 1 SALT
MODE: AUTO BLAST: 0270 M99%
SENSOR: 0050 RATE1: 0032
NULL: 15.0 75.0 WT/REV: 1.00
GAIN: 60% CAL GATE: 05
AUTONULL AUTOCAL
PPAGE NPAGE START SKIP ENTER
* SPINNER
MODE: MANUAL
NULL: 15.0 75.0
BLAST: 0 0 0
PPAGE
SKIP ENTER ENTER
* PREWET 1 LIQ1
MODE: VFLOW
RATE1: 0010
NULL: 15.0 75.0 PLS/LT: 1.00
AUTONULL AUTOCAL
PPAGE NPAGE START SKIP ENTER
