1 Mechanical Installation
1.1 Visual Check
After unpacking the frequency converter, perform a thorough visual check.
Check the following:
● Has the right device been supplied?
● Is the device damaged?
● Check the case for transport damage such as scratches, cracks or dents.
If you find a deviation from one of the above points, please contact your
Bosch Rexroth sales partner.
1.2 Ambient Conditions
If it is to function perfectly, the frequency converter must be installed in an envi-
ronment matching the data provided below.
Ambient temperature
-10...+40 °C (No derating)
+40...+50 °C (Derating
①
)
Max. altitude
Up to 1,000 m (No derating)
1,000...4,000 m (1 % / 100 m)
Relative humidity < 90 %
Degrees of protection IP 20 (Control cabinet mounting)
Tab. 1-1: Ambient conditions
①
: See "9.2: Derating of Electrical Data" in the Instruction Manual.
Bosch Rexroth AG
Mechanical Installation
DOK-RCON01-FE*********-IN04-EN-P
1/31
