REXROTH Fe Series - 2 Electric Installation; Cable Specifications

2 Electric Installation
2.1 Cable Specifications
2.1.1 Connecting to the Mains
Cable specification for international without USA / Canada
● ONLY USE copper wires of 90 ℃ or above with XLPE or EPR insu-
lation according to IEC 60364-5-52.
● It is recommended to use shielded cables to connect the motor.
● The specification is based on the supply voltage of 3P 380 VAC.
Fe
Model
Fuse
Power cables installation mode PE
B1 B2 E Torque / Screw
Cable
size
Torque /Screw
[A]
[mm
2
] [mm
2
] [mm
2
]
[Nm / lb-in] (Mx)
[mm
2
]
[Nm / lb-in]
(Mx)
0K75 10 1.5 1.5 1.5 1.8 (M4) 10 1.8 (M4)
1K50 10 1.5 1.5 1.5 1.8 (M4)) 10 1.8 (M4)
2K20 16 1.5 1.5 1.5 1.8 (M4) 10 1.8 (M4)
4K00 20 2.5 2.5 2.5 1.8 (M4) 10 1.8 (M4)
5K50 25 4 4 2.5 1.8 (M4) 10 1.8 (M4)
7K50 25 4 4 2.5 1.8 (M4) 10 1.8 (M4)
11K0 32 6 6 4 2...2.8 (M5) 10 2...2.8 (M5)
15K0 50 10 10 10 2...2.8 (M5) 10 2...2.8 (M5)
18K5 63 16 16 10 4...5 (M6) 16 4...5 (M6)
22K0 80 16 25 16 4...5 (M6) 16 4...5 (M6)
30K0 100 25 – 25 4...5 (M6) 16 4...5 (M6)
37K0 125 25 25 25 4...5 (M6) 16 6...9 (M8)
45K0 160 50 – 50 6...9 (M8) 25 6...9 (M8)
55K0 160 50 – 50 6...9 (M8) 25 15...20 (M10)
75K0 250 95/2*50 – 95/2*50 15...20 (M10) 50 15...20 (M10)
90K0 250 95/2*50 – 95/2*50 15...20 (M10) 50 15...20 (M10)
110K 315 – – 150/2*70 15...20 (M10) 95 15...20 (M10)
132K 315 – – 150/2*70 20 (M12) 120 15...20 (M10)
160K 400 – – 240 20 (M12) 120 15...20 (M10)
Tab. 2-1: Fuse and cable dimensions for international without USA / Canada
