Cable specification for USA / Canada
● ONLY USE copper wires of 75 ℃ or above according to UL 508C.
● It is recommended to use shielded cables to connect the motor.
● The specification is based on the supply voltage of 3P 380 VAC.
● The cables connecting to PE terminal should assemble the UL cer-
tificated wire connector which has suitable rating for wire gauge!
Fe
Model
Fuse
Power cables PE
Cable size Torque / Screw Cable size Torque / Screw
[A] [AWG] [Nm / lb-in] (Mx) [AWG] [Nm / lb-in] (Mx)
0K75 6 14 1.8 (M4) 8 1.8 (M4)
1K50 10 14 1.8 (M4)) 8 1.8 (M4)
2K20 15 14 1.8 (M4) 8 1.8 (M4)
4K00 25 10 1.8 (M4) 8 1.8 (M4)
5K50 30 10 1.8 (M4) 8 1.8 (M4)
7K50 40 10 1.8 (M4) 8 1.8 (M4)
11K0 50 6 2...2.8 (M5) 8 2...2.8 (M5)
15K0 60 6 2...2.8 (M5) 8 2...2.8 (M5)
18K5 80 4 4...5 (M6) 8 4...5 (M6)
22K0 80 4 4...5 (M6) 8 4...5 (M6)
30K0 100 3 4...5 (M6) 8 4...5 (M6)
37K0 125 3 4...5 (M6) 6 6...9 (M8)
45K0 150 2/0 6...9 (M8) 6 6...9 (M8)
55K0 175 2/0 6...9 (M8) 6 15...20 (M10)
75K0 225 4/0 15...20 (M10) 4 15...20 (M10)
90K0 250 4/0 15...20 (M10) 4 15...20 (M10)
110K 300 350 kcmil 15...20 (M10) 4 15...20 (M10)
132K 400 750 kcmil 20 (M12) 3 15...20 (M10)
160K 450 750 kcmil 20 (M12) 2 15...20 (M10)
Tab. 2-2: Fuse and cable dimensions for USA / Canada
