REXROTH Fv Series Quick Start Guide

2 Electric Installation
2.1 Cable Specifications
2.1.1 Connecting to the Mains
Cable specification for international without USA / Canada
● ONLY USE copper wires of 90 ℃ or above with XLPE or EPR insu-
lation according to IEC 60364-5-52.
● It is recommended to use shielded cables to connect the motor.
● The specification is based on the supply voltage of 3P 380 VAC.
Fv
Model
Fuse
Power cables installation mode PE
B1 B2 E Torque / Screw
Cable
size
Torque / Screw
[A]
[mm
2
] [mm
2
] [mm
2
]
[Nm / lb-in] (Mx)
[mm
2
]
[Nm / lb-in] (Mx)
0K40 6 1.5 1.5 1.5 1.7 / 15 (M4) 10 1.7 / 15 (M4)
0K75 10 1.5 1.5 1.5 1.7 / 15 (M4) 10 1.7 / 15 (M4)
1K50 10 1.5 1.5 1.5 1.7 / 15 (M4) 10 1.7 / 15 (M4)
2K20 16 1.5 1.5 1.5 1.7 / 15 (M4) 10 1.7 / 15 (M4)
4K00 20 2.5 2.5 2.5 1.7 / 15 (M4) 10 1.7 / 15 (M4)
5K50 25 4 4 2.5 1.7 / 15 (M4) 10 1.7 / 15 (M4)
7K50 25 4 4 2.5 1.7 / 15 (M4) 10 1.7 / 15 (M4)
11K0 40 6 6 6 2.7 / 24 (M5) 10 2.0 / 18 (M5)
15K0 50 10 10 10 2.7 / 24 (M5) 10 2.0 / 18 (M5)
18K5 63 25 25 16 2.5 / 22 (M6) 16 2.5 / 22 (M6)
22K0 80 25 25 16 2.5 / 22 (M6) 16 2.5 / 22 (M6)
30K0 100 25 – 25 2.5 / 22 (M6) 16 2.5 / 22 (M6)
37K0 125 25 – 25 2.5 / 22 (M6) 16 2.5 / 22 (M6)
45K0 160 50 – 50 8 / 71 (M8) 25 8 / 71 (M8)
55K0 160 50 – 50 8 / 71 (M8) 25 8 / 71 (M8)
75K0 200
95 /
2*50
–
70 /
2*35
15...20 /
133...177 (M10)
50
15...20 /
133...177 (M10)
90K0 250
95 /
2*50
–
95 /
2*50
15...20 /
133...177 (M10)
50
15...20 /
133...177 (M10)
Tab. 2-1: Cable specification for international without USA / Canada
Bosch Rexroth AG
Electric Installation
DOK-RCON02-FV*********-IN05-EN-P
7/39
