3.4 Parameters
3.4.1 Description of Attribute Symbols in Parameter Tables
Parameter
attribute
Description
◇ Parameter setting can be modified when the frequency converter is in run or stop mode.
◆ Parameter setting cannot be modified when the frequency converter is in run mode.
◎ Parameter setting is a calculated, measured or recorded value which cannot be modified.
Tab. 3-1: Parameter attributes and descriptions
Code: means function / parameter code, written in bx.xx, Sx.xx,
Ex.xx and Hx.xx.
Value of function / parameter code: written in [bx.xx], [Sx.xx],
[Ex.xx] and [Hx.xx].
Default: values that correspond to the factory default upon initializa-
tion at 50 Hz.
Attrib.: means attribute.
3.4.2 Quick Start Parameters
Access & motor nameplate parameters
Code
Name Setting range Min.unit Default Attrib.
b0.11 Parameter filter setting
0: b Parameters
1: b, S Parameters
2: b, S, E Parameters
3: b, S, E, H Parameters
1 0 ◇
S2.00 Rated motor frequency 8.00...400.00 Hz 0.01 50.00 ◆
S2.01 Rated motor rotation speed 1...24,000 rpm 1 1,440 ◆
S2.02 Rated motor power 0.4...1,000.0 kW 0.1
Depends
on model
◆
S2.03 Rated motor voltage 0...900 V 1 ◆
S2.04 Rated motor current 0.1...1,000.0 A 0.1 ◆
Bosch Rexroth AG
Parameter Settings
26/39
DOK-RCON02-FV*********-IN05-EN-P
