REXROTH Fv Series Quick Start Guide

Cable specification for USA / Canada
● ONLY USE copper wires of 75 ℃ or above according to UL 508C.
● It is recommended to use shielded cables to connect the motor.
● The specification is based on the supply voltage of 3P 380 VAC.
● The cables connecting to PE terminal should assemble the UL cer-
tificated wire connector which has suitable rating for wire gauge!
Fv
Model
Fuse
Power cables PE
Cable size Torque / Screw Cable size Torque / Screw
[A] [AWG] [Nm / lb-in] (Mx) [AWG] [Nm / lb-in] (Mx)
0K40 6 14 1.7 / 15 (M4) 8 1.7 / 15 (M4)
0K75 6 14 1.7 / 15 (M4) 8 1.7 / 15 (M4)
1K50 10 14 1.7 / 15 (M4) 8 1.7 / 15 (M4)
2K20 15 14 1.7 / 15 (M4) 8 1.7 / 15 (M4)
4K00 20 12 1.7 / 15 (M4) 8 1.7 / 15 (M4)
5K50 30 10 1.7 / 15 (M4) 8 1.7 / 15 (M4)
7K50 40 10 1.7 / 15 (M4) 8 1.7 / 15 (M4)
11K0 50 6 2.7 / 24 (M5) 8 2.0 / 18 (M5)
15K0 60 4 2.7 / 24 (M5) 8 2.0 / 18 (M5)
18K5 80 4 2.5 / 22 (M6) 8 2.5 / 22 (M6)
22K0 80 4 2.5 / 22 (M6) 8 2.5 / 22 (M6)
30K0 100 2 2.5 / 22 (M6) 8 2.5 / 22 (M6)
37K0 125 2 2.5 / 22 (M6) 6 2.5 / 22 (M6)
45K0 150 1/0 8 / 71 (M8) 6 8 / 71 (M8)
55K0 175 1/0 8 / 71 (M8) 6 8 / 71 (M8)
75K0 225 4/0
15...20 /
133...177 (M10)
4
15...20 /
133...177 (M10)
90K0 250 4/0
15...20 /
133...177 (M10)
4
15...20 /
133...177 (M10)
Tab. 2-2: Cable specification for USA / Canada
Bosch Rexroth AG
Electric Installation
DOK-RCON02-FV*********-IN05-EN-P
9/39
