REXROTH IndraDrive Fc FCS01 User Manual

1-4 Introduction Rexroth IndraDrive FCS01.1
DOK-INDRV*--FCS01*****-IB01_EN-P
1.3 Introducing the System
The Rexroth IndraDrive Fc drive system comprises the individual
components (the system elements) which are required for application and
utilization in the respective case:
• FCS01 frequency converter
• FCC01 function module
• FWA-INDRV*-FCB firmware
• Standard asynchronous motor
• Power transformer as an optional component
• Mains filter as an optional components
• Mains choke as optional components
• Braking resistor as additional component
System Elements - Components of the System
The drive system Rexroth IndraDrive Fc consists of the following system
elements:
System elements Types Characteristics Requirement
autotransformer DST optionaltransformer
isolating
transformer
DLT optional
1-phase NFE optionalmains filter
3-phase NFD03.1;
HNF01.1;
optional
mains choke standard FNL01.1E optional
Frequency converter single-axis FCS01.1 standard
firmware FCB01 standard
control panels FCC01.1T optionalFunction module
Field bus module FCC01.1F optional
Braking resistor FLR01.1 optional
Output throttle FML01 optional
shielded RKL standardMotor cable
unshielded RKL optional
Motor Standard asyn-
chronous motor
standard
Fig. 1-4: System elements Rexroth IndraDrive
Rexroth IndraDrive C and Rexroth IndraDrive Fc
Differences
Compared to the units HCS02 and HCS03 of the IndraDrive C product
family, the FCS01 units of the IndraDrive FC product family display a
narrower power range, and their functionality scalability is smaller than
that of the former. Primarily the FCS01 unit specialize in OpenLoop
operation.
Compatibility
It is not possible to couple the FCS01 units via a shared DC bus to the
HCS02 units.
Drive System,
Definition of Term
