Parameter Setting value / description / note Device Supervisor
Parameter
record
14 = Actual value process controller *; activates the process controller, and the
analog input 1 is connected with the actual value encoder (dancer, pressure box,
flow meter,…). The mode (0-10V or 0/4-20mA) is set in P401.
15 = Setpoint process controller *, same as function 14, but the setpoint (e.g. of a
potentiometer) is preset. The actual value must be preset via another input.
16 = Rate-action process controller *, adds an additional settable setpoint value
after the process controller.
*) for more details on the process controller, please refer to Chapter 12.4, Additional
Information.
**) The limits of these values are determined by the parameter >Minimum frequency
secondary setpoints< P410 and the parameter >Maximum frequency secondary
setpoints< P411.
Digital functions:
21 = Release right
22 = Release left
23 = Reversal of rotation direction
24 = Fixed frequency 1
25 = Fixed frequency 2
26 = Fixed frequency 3
27 = Fixed frequency 4
28 = reserved
29 = Hold frequency
30 = Voltage disable
31 = Quick stop
32 = Error confirmation
33 = PC thermistor input
34 = Remote control
35 = Jog frequency
36 = Hold frequency motor potentiometer
37 = reserved
38 = Watchdog
39 = Setpoint 1 on / off
40 = Setpoint 2 on / off
41 = Fixed frequency 5
42 = … 49 reserved
50 = PID controller on / off
51 = Disable release right
52 = Disable release left
53 = … 66 reserved
67 = Increase motor potentiometer jog
frequency
68 = Reduce motor potentiometer jog
frequency
69 = reserved
70 = Bit 0 fixed frequency array
71 = Bit 1 fixed frequency array
72 = Bit 2 fixed frequency array
73 = Bit 3 fixed frequency array
74 = Bit 4 fixed frequency array
75 = … 82 reserved
A more detailed description of the digital functions follows after the explanation of
parameters P420…P424. The functions of the digital inputs coincide with the digital functions
of the analog inputs.

REXROTH IndraDrive Fc FCS01 Specifications

General

Category	Controller
Control Voltage	24V DC
Communication Interface	SERCOS III, Ethernet/IP, PROFINET, EtherCAT, PROFIBUS
Cooling Method	Natural convection
Power section	Integrated
Protection class	IP20
Type	FCS01
Current Rating	Dependent on model
Dimensions	Dependent on model
Input voltage range	3 x AC 380V-480V
Output current	Dependent on model
Ambient temperature range	0°C to +45°C
Storage temperature range	-25 to +70 °C
Relative humidity	5% to 85%, non-condensing
Weight	Varies depending on model (refer to datasheet)
