Table 10. Technical Data
Parameter
Unit Size
Unit of
Measurement
130 180 260 310
Output velocity
883 962 924 894 fpm
269 293 282 272 Meter/minute
Standard open fan motor size
1/4 1/2 Horsepower
Optional enclosed fan motor size
Fan motor speed 1050 1050 rpm
Fan diameter 18 24 Inches
Approximate condensate per hour
1 2 Gallons
3.8 7.6 Liters
INSTALLATION
Unpacking and Inspection
• The unit was test-operated and inspected at the factory prior to crating and was in operating condition.
• It is important to note when uncrating the unit that shipping brackets are attached with cabinet screws. When
removing shipping brackets, re-insert ALL screws into the cabinet.
• If, upon removing it from its crate, the unit has been found to have incurred any damage in shipment, document
the damage with the transporting agency and contact an authorized Factory Distributor. If you are an authorized
Distributor, follow the FOB freight policy procedures.
• A conversion kit is included with the heater for converting for use with propane (refer to Converting Unit from
Natural Gas to Propane. section).
Pre-Installation Checklist
Check the rating plate for the gas specifications and electrical characteristics of the heater to ensure that they
are compatible with the gas and electric supplies at the installation site.
Read this manual and become familiar with the installation requirements of your particular heater.
If you do not have knowledge of local requirements, check with the local gas company or any other local agencies
who might have requirements concerning this installation.
Before beginning, make preparations for necessary supplies, tools, and manpower.
Check to see if there are any field-installed options (refer to Table 11) that need to be assembled/installed
prior to unit installation. Ensure that all options ordered are at the installation site. Instructions are in this
manual or in the option package (option packages are shipped separately).
14
I-UEZ (04-21) 1034347-0
—Continued
GENERAL INFORMATION—CONTINUED
Technical Data—Continued
Table 11. Field-Installed Options
Name Code Description
Vent/combustion air inlet terminal kit
CC2 Vertical roof vent
CC6 Horizontal through-wall vent
Vertical louvers CD1 —
Downturn nozzle
CD2 25- to 65-degree variable air deflection range
CD3 50- to 90-degree variable air deflection range
CD4 25- to 65-degree variable air deflection range nozzle with vertical louvers
Manual shutoff valve CE1 Natural gas or propane
Hanger kit CK10 Adapts 3/8-inch hangers for suspension from 1-inch threaded pipe
