Figure 12. Heater Assembly: Model Linear 100-S50, 125-S50, 150-S50, 170-S50, and 200-S50
G
F
G GH
S F
COUPLER
* (HIGH TEMP
COUPLER
MODELS 125,
150, 170 & 200)
BURNER
END
CAPS
(OPTIONAL)
6"
4"
51'6½" NOMINAL OVERALL ASSEMBLED LENGTH
END
CAPS
(OPTIONAL)
DISTANCE BETWEEN
SUSPENSION
POINTS NOT TO
EXCEED 12'
10' 3" REFLECTORS
TYPICAL OF 5
G
S
BURNER INSERT
(SEE DETAIL)
NAT GAS ONLY
6" REFLECTOR
OVERLAP
FIRST SUSPENSION POINT TUBE STRAP
DETAIL
TUBE & REFLECTOR SUSPENSION BRACKET
DETAIL
DETAIL
SLIDING REFLECTOR BRACKET
DETAIL
FIXED REFLECTOR BRACKET
REFLECTOR
TUBE
STRAP
RADIANT
TUBE
2 x SCREWS TIGHTEN TO
FIX REFLECTOR
2 x SCREWS MIN 1/8" GAP TO
ALLOW REFLECTOR TO SLIDE
SUPPLIED
NUT &
BOLT
H G
SF
STANDARD 4" COUPLER
6" REFLECTOR
OVERLAP
COUPLER
*(HIGH TEMP
COUPLER
MODEL 170 & 200)
G
F
3" REFLECTOR
OVERLAP
3" REFLECTOR
OVERLAP
TUBE
STRAP
RADIANT
TUBE
SUPPLIED
NUT & BOLT
SUSPENSION
BRACKET
REFLECTOR
"A"
VIEW ON "A"
COUPLERCOUPLER
C
L
2" MINIMUM
REFLECTOR OVERLAP
BURNER INSERT DETAIL PT. NO. 270489
NOTE: FOR MODEL 100 NAT GAS ONLY
