23
Figure 13. Heater Assembly: Model Linear 125-S60, 150-S60, 170-S60 and 200-S60
DETAIL
SLIDING REFLECTOR BRACKET
DETAIL
FIXED REFLECTOR BRACKET
REFLECTOR
TUBE
STRAP
RADIANT
TUBE
2 x SCREWS TIGHTEN TO
FIX REFLECTOR
2 x SCREWS MIN 1/8" GAP TO
ALLOW REFLECTOR TO SLIDE
SUPPLIED
NUT &
BOLT
SF
G GH
S
BURNER
END
CAPS
(OPTIONAL)
6"
4"
61'6½" NOMINAL OVERALL ASSEMBLED LENGTH
END
CAPS
(OPTIONAL)
DISTANCE BETWEEN
SUSPENSION
POINTS NOT TO
EXCEED 12'
10' 3" REFL'S
TYPICAL OF 6
GGG
S
COUPLER
*(HIGH TEMP
COUPLER
MODELS 170 & 200)
6" OVERLAP
G
F
*HT COUPLER
6" OVERLAP
F
3" OVERLAP
F
3" OVERLAP
S
3" OVERLAP
C
L
2" MINIMUM
REFLECTOR OVERLAP
STANDARD 4" COUPLER
FIRST SUSPENSION POINT TUBE STRAP
DETAIL
TUBE & REFLECTOR SUSPENSION BRACKET
DETAIL
TUBE
STRAP
RADIANT
TUBE
SUPPLIED
NUT & BOLT
SUSPENSION
BRACKET
REFLECTOR
H G
"A"
VIEW ON "A"
COUPLER
COUPLERCOUPLER
