Reznor VPS - Page 28

28
Figure 18. Heater Assembly: Model U tube 125-U60, 150-U60, 170-U60 and 200-U60
6"-9" REFLECTOR OVERLAPS
F
HT COUPLER
BURNER
END
CAPS
(OPTIONAL)
6"
4"
10' 3" REFLECTORS TYPICAL OF 6
F
DISTANCE BETWEEN
SUSPENSION POINTS
NO TO EXCEED 12'
32'1½" NOMINAL OVERALL ASSEMBLED LENGTH
DETAIL
SLIDING REFLECTOR BRACKET
DETAIL
FIXED REFLECTOR BRACKET
REFLECTOR
TUBE
STRAP
RADIANT
TUBE
2 x SCREWS TIGHTEN TO
FIX REFLECTOR
2 x SCREWS MIN 1/8" GAP TO
ALLOW REFLECTOR TO SLIDE
SUPPLIED
NUT &
BOLT
SF
GGH
3' 3"
G
G
G
F F
6" REFLECTOR OVERLAPS
S
COUPLER
*(HIGH TEMP
COUPLER
MODELS 170 &
200)
G
G
S
C
L
2" MINIMUM
REFLECTOR OVERLAP
FIRST SUSPENSION POINT TUBE STRAP
DETAIL
TUBE & REFLECTOR SUSPENSION BRACKET
DETAIL
TUBE
STRAP
RADIANT
TUBE
SUPPLIED
NUT & BOLT
SUSPENSION
BRACKET
REFLECTOR
H G
"A"
VIEW ON "A"
STANDARD 4" COUPLER
