Reznor VPS - Page 29

29
Figure 19. Heater Assembly: Model U tube 170-U80 and 200-U80
F
HT COUPLER
BURNER
END
CAPS
(OPTIONAL)
6"
4"
10' 3" REFLECTORS TYPICAL OF 8
S
DISTANCE BETWEEN
SUSPENSION POINTS NO TO
EXCEED 12'
42'1½" NOMINAL OVERALL ASSEMBLED LENGTH
DETAIL
SLIDING REFLECTOR BRACKET
DETAIL
FIXED REFLECTOR BRACKET
REFLECTOR
TUBE
STRAP
RADIANT
TUBE
2 x SCREWS TIGHTEN TO
FIX REFLECTOR
2 x SCREWS MIN 1/8" GAP TO
ALLOW REFLECTOR TO SLIDE
SUPPLIED
NUT &
BOLT
SF
GGH
3' 3"
GGG
F S
6" REFLECTOR OVERLAPS
S
HT COUPLER
G
G
S
3" REFLECTOR OVERLAPS
F
COUPLER
G
G
F
6"-9" REFLECTOR OVERLAPS
C
L
2" MINIMUM
REFLECTOR OVERLAP
FIRST SUSPENSION POINT TUBE STRAP
DETAIL
TUBE & REFLECTOR SUSPENSION BRACKET
DETAIL
TUBE
STRAP
RADIANT
TUBE
SUPPLIED
NUT & BOLT
SUSPENSION
BRACKET
REFLECTOR
H G
"A"
VIEW ON "A"
STANDARD 4" COUPLER
