RGBlink M1 Quick Start

19
/25
Standard C_1024×768@60
Custom Format On
HActive 1024
VActive 768
Freq 60
Set >>
Set the Output Parameter
1. Select the Output Resolution
Push the [MENU] button, and enter to the menu items, turn the rotary knob and select <Output> or :
Push the rotary knob to confirm, and enter to the menus as below:
<Output Format> is the default option, push the rotary to confirm. Turn the rotary knob, select the output
resolution according to actual need.
Customs Output Resolution
Continue the above operation, setting the HActive, VActive, Freq, and select <Set>, confirm the Set setting to
Yes.Then the LCD screen shown as below:
2. Output Setting
Push the rotary knob or touch the button <Output setting> to confirm, and enter to the menus as below:
PST and PGM can be choose DVI or HDMI as output port, SDI Level choose Level A or Level B.
Output Format
Output Setting
External Sync
Test Pattern
PST DVI
PGM DVI
SDI Level Level A
