Rheem 13 Series User Manual

5
Height “H” (in.) [mm]
DIMENSIONAL DATA
18, 24
18, 24
26
1
/4 [666.7]
Length “L” (in.) [mm]
23
5
/8 [600]
Width “W” (in.) [mm]
23
5
/8 [600]
BASE PAN (BOTTOM VIEW)
DO NOT OBSTRUCT DRAIN HOLES
(SHADED).
13 SEER
Cooling Capacity
14 SEER
Cooling Capacity
30
30
36
36
42, 48, 60
42, 48, 60
26
1
/4 [666.7] 27
3
/8 [695.3] 35
3
/8 [898.5]
27
5
/8 [701.6] 31
5
/8 [803.2] 31
5
/8 [803.2]
27
5
/8 [701.6]
31
5
/8 [803.2]
31
5
/8 [803.2]
FIGURE 1
DIMENSIONS
2.3 DIMENSIONS (SEE FIGURE 1)
AIR DISCHARGE: ALLOW
60” [1524 mm] MINIMUM
CLEARANCE.
L
H
SEE DETAIL A
w
A-00008
SERVICE ACCESS
ALLOW 24” [609.6 mm]
CLEARANCE
AIR INLETS
(LOUVERED PAN-
ELS) ALLOW 6”
[152.4 mm]
MINIMUM
CLEARANCE
2"
[50.8 mm]
BASERAIL*
NOTE: GRILLE APPEARANCE
MAY VARY.
*The 3, 3
1
⁄2, 4 & 5 ton
models do not feature
a baserail.

Rheem 13 Series Specifications

General

Refrigerant	R-410A
Voltage	208/230V
Compressor Type	Scroll
Cooling Capacity	18, 000-60, 000 BTU/h
Heating Capacity	18, 000-60, 000 BTU/h
Stages	Single
