• Each fault is displayed one time with the top right hand segment of the dual 7-
segment display activated between faults.
• Each fault is displayed with the most recent fault displayed first.
• A maximum of six individual faults can be stored
• A maximum of three consecutive identical faults are stored.
• A “0” will be displayed with no faults are stored
• The ICC will automatically exit the
FFAAUULLTT RREECCAALLLL
mode after displaying stored
faults
CClleeaarr FFaauulltt HHiissttoorryy ((TTEESSTT aanndd SSWW22 BBuuttttoonnss))
• Clear FAULT HISTORY by pressing both TEST and SW2 button for five (5) sec-
onds with insulated probes and release.
• The top and bottom segments of the dual 7-segment LEDs flash to indicate the
history has been cleared.
Fault history is cleared with the top and bottom LED
segments flash
NOTE: The memory card for the unit has specific shared data for this unit. The
memory card is attached to the control box with a tether. The tether has an identifi-
cation tag that can be used to identify the memory card. For the system data faults
d1 through d8 reference the label on the memory card tether.
9
• A maximum of six individual faults can be stored
• A maximum of three consecutive identical faults are stored.
• A “0” will be displayed with no faults are stored
• The ICC will automatically exit the FAULT RECALL mode after displaying stored faults
I
MPORTANT: The ICC stores the previous two weeks of history faults. The complete stored
fault history can be displayed using the serial communicating thermostat. Refer to the thermostat
literature for information on accessing fault history.
Clear Fault History (TEST and SW2 Buttons)
• Clear FAULT HISTORY by pressing both TEST and SW2 button for five (5) seconds with
insulated probes and release.
• The top and bottom segments of the 7-segment LEDs flash to indicate the history has been
cleared.
Fault history is cleared with the top and bottom LED segments flash
COMFORT CONTROL
2
SYSTEM™ CONTROL WIRING
24
