• Each fault is displayed one time with the top right hand segment of the dual 7-
segment display activated between faults.
• Each fault is displayed with the most recent fault displayed first.
• A maximum of six individual faults can be stored
• A maximum of three consecutive identical faults are stored.
• A “0” will be displayed with no faults are stored
• The ICC will automatically exit the
FFAAUULLTT RREECCAALLLL
mode after displaying stored
faults
IIMMPPOORRTTAANNTT::
The ICC stores the previous six history faults. The complete stored
fault history cannot be displayed using a conventional thermostat.
CClleeaarr FFaauulltt HHiissttoorryy ((TTEESSTT aanndd SSWW22 BBuuttttoonnss))
• Clear FAULT HISTORY by pressing both TEST and SW2 button for five (5) sec-
onds with insulated probes and release.
• The top and bottom segments of the dual 7-segment LEDs flash to indicate the
history has been cleared.
Fault history is cleared with the top and bottom LED
segments flash
8
Fault Recall Mode (TEST and SW2 Buttons)
• Enter FAULT RECALL mode by pressing the TEST and SW2 buttons at the same time
with insulated probes for one (1) second and release.
• When entering and exiting FAULT RECALL mode the top and bottom segments of the 7-
segment LEDs will illuminate.
Fault Recall Mode – the top and bottom segments illuminated
• When entering FAULT RECALL mode, the ICC will automatically scroll through stored
faults on the 7-segment LEDs.
• Each fault is displayed one time with the top segment of the 7-segment display activated
between faults.
• Each fault is displayed with the most recent fault displayed first.
• A maximum of six individual faults can be stored
• A maximum of three consecutive identical faults are stored.
• A “0” will be displayed with no faults are stored
• The ICC will automatically exit the FAULT RECALL mode after displaying stored faults
IMPORTANT: The ICC stores the previous two weeks of history faults. The complete stored
fault history cannot be displayed using a conventional thermostat.
Clear Fault History (TEST and SW2 Buttons)
• Clear FAULT HISTORY by pressing both TEST and SW2 button for five (5) seconds with
insulated probes and release.
• The top and bottom segments of the 7-segment LEDs flash to indicate the history has been
cleared.
Fault history is cleared with the top and bottom LED segments flash
CONVENTIONAL THERMOSTAT WIRING
35
