GENERAL DATA - RJNL MODELS
NOMINAL SIZES 3-5 TONS [10.6-17.6 kW]
Model RJNL- Series A036DL A036DM A036JK A042CK
Cooling Performance
1
Continued ->
Gross Cooling Capacity Btu [kW] 37,800 [11.08] 37,800 [11.08] 37,800 [11.08] 44,000 [12.89]
EER/SEER
2
11.5/13 11.5/13 11.5/13 11.2/13
Nominal CFM/ARI Rated CFM [L/s] 1200/1200 [566/566] 1200/1200 [566/566] 1200/1200 [566/566] 1400/1400 [661/661]
ARI Net Cooling Capacity Btu [kW] 36,200 [10.61] 36,200 [10.61] 36,200 [10.61] 42,000 [12.31]
Net Sensible Capacity Btu [kW] 27,000 [7.91] 27,000 [7.91] 27,000 [7.91] 31,200 [9.14]
Net Latent Capacity Btu [kW] 9,200 [2.7] 9,200 [2.7] 9,200 [2.7] 10,800 [3.16]
Net System Power kW 3.1 3.1 3.1 3.74
Heating Performance (Heat Pumps)
High Temp. Btuh [kW] Rating 34,400 [10.08] 34,400 [10.08] 34,400 [10.08] 41,000 [12.01]
System Power KW / COP 2.94/3.4 2.94/3.4 2.94/3.4 3.38/3.5
Low Temp. Btuh [kW] Rating 19,600 [5.74] 19,600 [5.74] 19,600 [5.74] 24,400 [7.15]
System Power KW / COP 2.72/2.1 2.72/2.1 2.72/2.1 3.12/2.3
HSPF (Btu/Watts-hr) 7.7 7.7 7.7 7.7
Compressor
No./Type 1/Copeland Scroll 1/Copeland Scroll 1/Copeland Scroll 1/Copeland Scroll
Outdoor Sound Rating (dB)
83 83 83 83
Outdoor Coil - Fin Type Louvered Louvered Louvered Louvered
Tube Type Rifled Rifled Rifled Rifled
Tube Size in. [mm] OD 0.375 [9.5] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5]
Face Area sq. ft. [sq. m] 16.89 [1.57] 16.89 [1.57] 16.89 [1.57] 16.89 [1.57]
Rows / FPI [FPcm] 1 / 22 [9] 1 / 22 [9] 1 / 22 [9] 1 / 22 [9]
Refrigerant Control TX Valves TX Valves TX Valves TX Valves
Indoor Coil - Fin Type Louvered Louvered Louvered Louvered
Tube Type Rifled Rifled Rifled Rifled
Tube Size in. [mm] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5]
Face Area sq. ft. [sq. m] 5.16 [0.48] 5.16 [0.48] 5.16 [0.48] 5.16 [0.48]
Rows / FPI [FPcm] 3 / 13 [5] 3 / 13 [5] 3 / 13 [5] 3 / 13 [5]
Refrigerant Control TX Valves TX Valves TX Valves TX Valves
Drain Connection No./Size in. [mm] 1/0.75 [19.5] 1/0.75 [19.5] 1/0.75 [19.5] 1/0.75 [19.5]
Outdoor Fan - Type Propeller Propeller Propeller Propeller
No. Used/Diameter in. [mm] 1/24 [609.6] 1/24 [609.6] 1/24 [609.6] 1/24 [609.6]
Drive Type/No. Speeds Direct/1 Direct/1 Direct/1 Direct/1
CFM [L/s] 4000 [1888] 4000 [1888] 4000 [1888] 4000 [1888]
No. Motors/HP 1 at 1/3 HP 1 at 1/3 HP 1 at 1/3 HP 1 at 1/3 HP
Motor RPM 1075 1075 1075 1075
Indoor Fan - Type FC Centrifugal FC Centrifugal FC Centrifugal FC Centrifugal
No. Used/Diameter in. [mm] 1/10x10 [254x254] 1/10x10 [254x254] 1/10x10 [254x254] 1/10x10 [254x254]
Drive Type/No. Speeds Belt/Variable Belt/Variable Direct/3 Direct/3
No. Motors 1 1 1 1
Motor HP 1/2 3/4 1/2 1/2
Motor RPM 1725 1725 1075 1075
Motor Frame Size 56 56 48 48
Filter - Type Disposable Disposable Disposable Disposable
Furnished Yes Yes Yes Yes
(NO.) Size Recommended in. [mm x mm x mm] (2)1x25x16 [25x635x406] (2)1x25x16 [25x635x406] (2)1x25x16 [25x635x406] (2)1x25x16 [25x635x406]
Refrigerant Charge Oz. [g] 116 [3289] 116 [3289] 116 [3289] 120 [3402]
Weights
Net Weight lbs. [kg] 517 [235] 517 [235] 517 [235] 521 [236]
Ship Weight lbs. [kg] 532 [241] 532 [241] 532 [241] 536 [243]
3
NOTES:
1. Cooling Performance is rated at 95° F ambient, 80° F entering dry bulb, 67° F entering wet bulb. Gross capacity does not include the effect of fan motor heat. ARI capacity
is net and includes the effect of fan motor heat. Units are suitable for operation to ±20% of nominal cfm. Units are certified in accordance with the Unitary Air Conditioner
Equipment certification program, which is based on ARI Standard 210/240 or 360.
2. EER and/or SEER are rated at ARI conditions and in accordance with DOE test procedures.
3. Outdoor Sound Rating shown is tested in accordance with ARI Standard 270.utdoor Sound Rating shown is tested in accordance with ARI Standard 270.
