208-240 VOLT, SINGLE PHASE, 60 HZ, AUXILLARY ELECTRIC HEATER KITS CHARACTERISTICS AND APPLICATION
Single Power Supply For Both Unit And Heater Kit Separate Power Supply For Both Unit And Heater Kit
Over Current Protective
Device Size
Min/Max @
208 V
Min/Max @
240 V
Min/Max @
208 V
Min/Max @
240 V
No Heat - - - 27/27 35/40 35/40 - - 27/27 35/40 35/40
A06J+ 4.2/5.6 14.33/19.10 20.2/23.3 52/56 60/60 60/60 26/30 30/30 - - -
A10J+ 7.2/9.6 24.56/32.75 34.7/40.0 70/77 70/70 80/80 44/50 45/50 - - -
*A11J+ 7.2/9.6 24.56/32.75 34.7/40.0 70/77 70/70 80/80 44/50 45/50 - - -
A12J+ 8.4/11.2 28.66/38.21 40.4/46.7 77/85 80/80 90/90 51/59 60/60 - - -
A15J+ 10.8/14.4 36.84/49.13 52.0/60.0 92/102 100/100 110/110 65/75 70/80 - - -
A20J+ 14.4/19.2 49.13/65.51 69.3/80.0 113/127 125/125 150/150 87/100 90/100 - - -
*A21J+ 14.4/19.2 49.13/65.51 69.3/80.0 113/127 125/125 150/150 87/100 90/100 - - -
No Heat - - 28/28 35/45 35/45 - - 28/28 35/45 35/45
A06J+ 4.2/5.6 14.33/19.10 20.2/23.3 54/58 60/60 60/60 26/30 30/30 - - -
A10J 7.2/9.6 24.56/32.75 34.7/40.0 72/78 80/80 80/80 44/50 45/50 - - -
*A11J+ 7.2/9.6 24.56/32.75 34.7/40.0 72/78 80/80 80/80 44/50 45/50 - - -
A12J+ 8.4/11.2 28.66/38.21 40.4/46.7 79/87 80/80 90/90 51/59 60/60 - - -
A15J 10.8/14.4 36.84/49.13 52.0/60.0 93/103 100/100 110/110 65/75 70/80 - - -
A20J+ 14.4/19.2 49.13/65.51 69.3/80.0 115/128 125/125 150/150 87/100 90/100 - - -
*A21J+ 14.4/19.2 49.13/65.51 69.3/80.0 115/128 125/125 150/150 87/100 90/100 - - -
No Heat - - - 33/33 40/50 40/50 - - 33/33 40/50 40/50
A06J+ 4.2/5.6 14.33/19.10 20.2/23.3 58/62 60/70 70/70 26/30 30/30 - - -
A10J+ 7.2/9.6 24.56/32.75 34.7/40.0 77/83 80/80 90/90 44/50 45/50 - - -
*A11J+ 7.2/9.6 24.56/32.75 34.7/40.0 77/83 80/80 90/90 44/50 45/50 - - -
A12J+ 8.4/11.2 28.66/38.21 40.4/46.7 84/92 90/90 100/100 51/59 60/60 - - -
A15J 10.8/14.4 36.84/49.13 52.0/60.0 98/108 100/100 110/110 65/75 70/80 - - -
A20J 14.4/19.2 49.13/65.51 69.3/80.0 120/133 125/125 150/150 87/100 90/100 - - -
*A21J+ 14.4/19.2 49.13/65.51 69.3/80.0 120/133 125/125 150/150 87/100 90/100 - - -
No Heat - - - 39/39 45/60 45/60 - - 39/39 45/60 45/60
A06J+ 4.2/5.6 14.33/19.10 20.2/23.3 64/68 70/80 70/80 26/30 30/30 - - -
A10J+ 7.2/9.6 24.56/32.75 34.7/40.0 82/89 90/90 90/100 44/50 45/50 - - -
*A11J+ 7.2/9.6 24.56/32.75 34.7/40.0 82/89 90/90 90/100 44/50 45/50 - - -
A12J+ 8.4/11.2 28.66/38.21 40.4/46.7 89/97 90/100 100/110 51/59 60/60 - - -
A15J 10.8/14.4 36.84/49.13 52.0/60.0 104/114 110/110 125/125 65/75 70/80 - - -
A20J 14.4/19.2 49.13/65.51 69.3/80.0 125/139 125/125 150/150 87/100 90/100 - - -
*A21J+ 14.4/19.2 49.13/65.51 69.3/80.0 125/139 125/125 150/150 87/100 90/100 - - -
Heater Kit
Min. Ckt.
Ampacity
Heater Kit
Max. Fuse
Size
Heat Pump
Min. Ckt.
Ampacity 208
To Next Page
