208-240 VOLT, THREE PHASE, 60 HZ, AUXILLARY ELECTRIC HEATER KITS CHARACTERISTICS AND APPLICATION
Single Power Supply For Both Unit And Heater Kit Separate Power Supply For Both Unit And Heater Kit
Over Current Protective
Device Size
Min/Max @
208 V
Min/Max @
240 V
Min/Max @
208 V
Min/Max @
240 V
No Heat - - - 19/19 25/25 25/25 - - 19/19 25/25 25/25
A06C+ 4.2/5.6 14.33/19.10 11.7/13.5 34/36 35/40 40/40 15/17 15/20 - - -
A10C+ 7.2/9.6 24.56/32.75 20.0/23.1 44/48 45/45 50/50 25/29 25/30 - - -
*A11C+ 7.2/9.6 24.56/32.75 20.0/23.1 44/48 45/45 50/50 25/29 25/30 - - -
A12C+ 8.4/11.2 28.66/38.21 23.4/27.0 48/53 50/50 60/60 30/34 30/35 - - -
A15C+ 10.8/14.4 36.84/49.13 30.1/34.7 57/62 60/60 70/70 38/44 40/45 - - -
A20C+ 14.4/19.2 49.13/65.51 40.1/46.2 69/77 70/70 80/80 50/58 50/60 - - -
*A21C+ 14.4/19.2 49.13/65.51 40.1/46.2 69/77 70/70 80/80 50/58 50/60 - - -
No Heat - - 23/23 30/35 30/35 - - 23/23 30/35 30/35
A06C+ 4.2/5.6 14.33/19.10 11.7/13.5 38/40 40/45 40/45 15/17 15/20 - - -
A10C+ 7.2/9.6 24.56/32.75 20.0/23.1 48/52 50/50 60/60 25/29 25/30 - - -
*A11C+ 7.2/9.6 24.56/32.75 20.0/23.1 48/52 50/50 60/60 25/29 25/30 - - -
A12C+ 8.4/11.2 28.66/38.21 23.4/27.0 52/57 60/60 60/60 30/34 30/35 - - -
A15C+ 10.8/14.4 36.84/49.13 30.1/34.7 61/66 70/70 70/70 38/44 40/45 - - -
A20C+ 14.4/19.2 49.13/65.51 40.1/46.2 73/81 80/80 90/90 50/58 50/60 - - -
*A21C+ 14.4/19.2 49.13/65.51 40.1/46.2 73/81 80/80 90/90 50/58 50/60 - - -
No Heat - - - 23/23 30/35 30/35 - - 23/23 30/35 30/35
A06C+ 4.2/5.6 14.33/19.10 11.7/13.5 38/40 40/45 40/45 15/17 15/20 - - -
A10C+ 7.2/9.6 24.56/32.75 20.0/23.1 48/52 50/50 60/60 25/29 25/30 - - -
*A11C+ 7.2/9.6 24.56/32.75 20.0/23.1 48/52 50/50 60/60 25/29 25/30 - - -
A12C+ 8.4/11.2 28.66/38.21 23.4/27.0 52/57 60/60 60/60 30/34 30/35 - - -
A15C+ 10.8/14.4 36.84/49.13 30.1/34.7 61/67 70/70 70/70 38/44 40/45 - - -
A20C+ 14.4/19.2 49.13/65.51 40.1/46.2 73/81 80/80 90/90 50/58 50/60 - - -
*A21C+ 14.4/19.2 49.13/65.51 40.1/46.2 73/81 80/80 90/90 50/58 50/60 - - -
No Heat - - - 25/25 30/40 30/40 - - 25/25 30/40 30/40
A06C+ 4.2/5.6 14.33/19.10 11.7/13.5 40/42 50/50 45/50 15/17 15/20 - - -
A10C+ 7.2/9.6 24.56/32.75 20.0/23.1 50/54 50/60 60/60 25/29 25/30 - - -
*A11C+ 7.2/9.6 24.56/32.75 20.0/23.1 50/54 50/60 60/60 25/29 25/30 - - -
A12C+ 8.4/11.2 28.66/38.21 23.4/27.0 55/59 60/60 60/60 30/34 30/35 - - -
A15C 10.8/14.4 36.84/49.13 30.1/34.7 63/69 70/70 70/70 38/44 40/45 - - -
A20C+ 14.4/19.2 49.13/65.51 40.1/46.2 76/83 80/80 90/90 50/58 50/60 - - -
*A21C+ 14.4/19.2 49.13/65.51 40.1/46.2 76/83 80/80 90/90 50/58 50/60 - - -
Heat Pump
Min. Ckt.
Ampacity 208
-
240
Heat Pump Over
Current Protective
Device Size
A048CK
A060CK
A036CK
A042CK
Heater
Amp. @ 208
-
240 V
Unit Min. Ckt
Ampacity @
208-240 V
Heater Kit
Min. Ckt.
Ampacity
Heater Kit
Max. Fuse
Size
Model
No.
RJNL-
RXJJ-
Heater Kit
Nominal kW
Rated Heater
kW @ 208-
240 V
Heater
KBTU/Hr @
208-240 V
