INDOOR AIRFLOW PERFORMANCE FOR 3-5 TON PACKAGE HEAT PUMPS – RJNL
DIRECT DRIVE
CFM [L/s] Air Delivery/Watts-208 VOLTS
External Static Pressure-Inches W.C.
Nominal
Cooling
Capacity
Tons
Motor Speed
From Factory
Manufacturer
Recommended
Airflow Range
(Min / Max) CFM
Blower Size/
Motor HP #
of Speeds
Motor
Speed
0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 1.00
10x10
CFM
1275 1235 1210 1181 1132 1045
3.0 Low 1050 / 1350 1/2 Low [602] [583] [571] [557] [534] [493]
3 Speed Watts 493 481 468 452 431 402
10x10
CFM
1397 1344 1319 1297 1249 1147
3.5 Low 1225 / 1575 1/2 Med [659] [634] [622] [612] [589] [541]
3 Speed Watts 561 537 522 508 488 454
10x10
CFM
1766 1719 1671 1617 1550 1465
4.0 Low 1400 / 1800 1/2 High [833] [811] [789] [763] [732] [691]
3 Speed Watts 735 719 697 671 639 603
CFM
1974 1935 1897 1860 1823 1788 1753 1719 1686
11x9 Low [932] [913] [895] [878] [860] [844] [827] [811] [796]
5.0 Low 1750 / 2250 1 Watts 490 505 510 545 555 575 600 605 625
2 Speed
CFM
2185 2148 2112 2076 2040 2005 1970 1935 1900
High [1031] [1014] [997] [980] [963] [946] [930] [913] [897]
Watts 675 685 700 720 735 750 770 780 805
CFM [L/s] Air Delivery/Watts-230/460 VOLTS
External Static Pressure-Inches W.C.
Nominal
Cooling
Capacity
Tons
Motor Speed
From Factory
Manufacturer
Recommended
Airflow Range
(Min / Max) CFM
Blower Size/
Motor HP #
of Speeds
Motor
Speed
0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 1.00
10x10
CFM
1455 1423 1388 1345 1289 1214
3.0 Low 1050 / 1350 1/2 Low [687] [627] [655] [635] [608] [573]
3 Speed Watts 578 565 549 528 502 472
10x10
CFM
1601 1561 1517 1466 1401 1317
3.5 Med 1225 / 1575 1/2 Med [756] [737] [716] [692] [661] [622]
3 Speed Watts 659 636 613 589 562 529
10x10
CFM
1964 1902 1839 1771 1693 1602
4.0 High 1400 / 1800 1/2 High [927] [898] [868] [836] [799] [756]
3 Speed Watts 847 811 780 751 721 688
CFM
1974 1935 1897 1860 1823 1788 1753 1719 1686
11x9 Low [932] [913] [895] [878] [860] [844] [827] [811] [796]
5.0 Low 1750 / 2250 1 Watts 490 505 510 545 555 575 600 605 625
2 Speed
CFM
2185 2148 2112 2076 2040 2005 1970 1935 1900
High [1031] [1014] [997] [980] [963] [946] [930] [913] [897]
Watts 675 685 700 720 735 750 770 780 805
DIRECT-DRIVE BLOWER 208 AIRFLOW PERFORMANCE
