49
INDOOR AIRFLOW PERFORMANCE FOR 3-5 TON PACKAGE HEAT PUMPS – RJPL
DIRECT DRIVE
DIRECT-DRIVE BLOWER 208/230/460 AIRFLOW PERFORMANCE
CFM Air Delivery/RPM/Watts-208/230 Volts
External Static Pressure-Inches W.C.
0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 1.00
CFM 1448 1413 1367 1325 1285 1242 1196 1106 1006
10x10
RPM 674 720 771 818 862 907 953 1019 1091
1/2 HP [373]
Watts 230 245 260 274 288 301 314 330 350
2 Speed
CFM 1618 1577 1516 1482 1443 1395 1359 1312 1261 1042
(X-13 Motor)
RPM 712 755 807 851 894 941 978 1019 1061 1137
Watts 299 315 332 350 364 380 391 402 414 392
CFM 1641 1603 1570 1534 1504 1468 1410 1359 1316 1252
10x10
RPM 724 764 806 852 895 933 985 1032 1076 1132
3/4 HP [559]
Watts 292 307 323 343 363 377 396 412 430 446
2 Speed
CFM 1735 1704 1674 1631 1598 1560 1527 1481 1437 1336
(X-13 Motor)
RPM 755 796 835 879 917 956 995 1044 1084 1133
Watts 340 360 378 396 411 427 443 464 479 482
CFM 1771 1739 1708 1670 1642 1607 1568 1511 1236
10x10
RPM 848 890 925 963 996 1032 1076 1121 1161
3/4 HP [559]
Watts 422 445 462 478 493 509 529 544 460
2 Speed
CFM 1954 1908 1878 1840 1797 1771 1692 1603 1457
(X-13 Motor)
RPM 914 949 984 1016 1055 1083 1114 1133 1154
Watts 547 565 585 601 619 634 634 605 550
CFM 1914 1882 1851 1817 1783 1753 1703 1688
10x10
Low RPM 778 805 835 861 894 926 959 988
1 HP [746]
Watts 496 514 533 544 565 584 604 618
2 Speed
CFM 2185 2148 2112 2076 2040 2005 1970 1935 1900
(X-13 Motor)
High RPM 846 871 895 920 950 984 1008 1042 1061
Watts 675 685 700 720 735 750 770 780 805
Nominal
Cooling
Capacity
Tons
Motor Speed
From Factor
y
Manufacturer
Recommended
Air-Flow Range
(
Min / Max
)
CFM
Blower Size/
Motor HP #
of S
p
eeds
3.5 Low (Tap 2) 1225 / 1575
Motor
S
p
eed
3.0 Low (Tap 2) 1050 / 1350
Low
High
Low
High
Low
High
5.0 Low (Tap 2) 1750 / 2250
4.0 Low (Tap 2) 1400 / 1800
CFM Air Delivery/RPM/Watts-208/230/460 Volts
