GENERAL DATA - RJPL MODELS
NOMINAL SIZES 3-5 TONS [10.6-17.6 kW]
NOTES:
1. Cooling Performance is rated at 95° F ambient, 80° F entering dry bulb, 67° F entering wet bulb. Gross capacity does not include the effect of fan motor heat. AHRI capaci-
ty is net and includes the effect of fan motor heat. Units are suitable for operation to ±20% of nominal cfm. Units are certified in accordance with the Unitary Air Conditioner
Equipment certification program, which is based on AHRI Standard 210/240 or 360.
2. EER and/or SEER are rated at AHRI conditions and in accordance with DOE test procedures.
3. Outdoor Sound Rating shown is tested in accordance with AHRI Standard 270.utdoor Sound Rating shown is tested in accordance with AHRI Standard 270.
M
odel RJPL - Series A060DK A060DL A060DM A060JK
C
ooling performance
1
G
ross Cooling Capacity Btu [kW] 61,000 [17.87] 61,000 [17.87] 61,000 [17.87] 61,000 [17.87]
EER, SEER
2
11.7/14 11.7/14 11.7/14 11.7/14
Nominal CFM/AHRI Rated CFM [L/s] 2000/1850 [944/873] 2000/1850 [944/873] 2000/1850 [944/873] 2000/1850 [944/873]
AHRI Net Cooling Capacity Btu [kW] 59,500 [17.43] 59,500 [17.43] 59,500 [17.43] 59,500 [17.43]
N
et Sensible Capacity Btu [kW] 43,600 [12.77] 43,600 [12.77] 43,600 [12.77] 43,600 [12.77]
N
et Latent Capacity Btu [kW] 15,900 [4.66] 15,900 [4.66] 15,900 [4.66] 15,900 [4.66]
N
et System Power kW 5.05 5.05 5.05 5.05
Heating Performance (Heat Pumps)
High Temp. Btuh [kW] Rating 59,500 [17.43] 59,500 [17.43] 59,500 [17.43] 59,500 [17.43]
System Power KW / COP 4.8/3.6 4.8/3.6 4.8/3.6 4.8/3.6
L
ow Temp. Btuh [kW] Rating 36,400 [10.67] 36,400 [10.67] 36,400 [10.67] 36,400 [10.67]
S
ystem Power KW / COP 4.47/2.2 4.47/2.2 4.47/2.2 4.47/2.2
HSPF (Btu/Watts-hr) 8888
Compressor
No/Type 1/Copeland Scroll 1/Copeland Scroll 1/Copeland Scroll 1/Copeland Scroll
O
utdoor Sound Rating (dB)
5
8
3 83 83 83
Outdoor Coil - Fin Type Louvered Louvered Louvered Louvered
Tube Type Rifled Rifled Rifled Rifled
T
ube Size in. [mm] OD 0.375 [9.5] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5]
F
ace Area sq. ft. [sq. m] 16.56 [1.54] 16.56 [1.54] 16.56 [1.54] 16.56 [1.54]
Rows / FPI [FPcm] 2 / 22 [9] 2 / 22 [9] 2 / 22 [9] 2 / 22 [9]
Refrigerant Control TX Valves TX Valves TX Valves TX Valves
I
ndoor Coil - Fin Type Louvered Louvered Louvered Louvered
Tube Type Rifled Rifled Rifled Rifled
Tube Size in. [mm] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5]
Face Area sq. ft. [sq. m] 5.16 [0.48] 5.16 [0.48] 5.16 [0.48] 5.16 [0.48]
Rows / FPI [FPcm] 4 / 13 [5] 4 / 13 [5] 4 / 13 [5] 4 / 13 [5]
Refrigerant Control TX Valves TX Valves TX Valves TX Valves
Drain Connection No./Size in. [mm] 1/0.75 [19.5] 1/0.75 [19.5] 1/0.75 [19.5] 1/0.75 [19.5]
Outdoor Fan - Type Propeller Propeller Propeller Propeller
No. Used/Diameter in. [mm] 1/24 [609.6] 1/24 [609.6] 1/24 [609.6] 1/24 [609.6]
Drive Type/No. Speeds Direct/1 Direct/1 Direct/1 Direct/1
CFM [L/s] 4000 [1888] 4000 [1888] 4000 [1888] 4000 [1888]
No. Motors/HP 1 at 1/3 HP 1 at 1/3 HP 1 at 1/3 HP 1 at 1/3 HP
Motor RPM 1075 1075 1075 1075
Indoor Fan - Type FC Centrifugal FC Centrifugal FC Centrifugal FC Centrifugal
No. Used/Diameter in. [mm] 1/11x9 [279x229] 1/10x10 [254x254] 1/10x10 [254x254] 1/11x9 [279x229]
Drive Type/No. Speeds Direct/2 Belt/Variable Belt/Variable Direct/2
No. Motors 1111
Motor HP 1 3/4 11
Motor RPM 1100 1725 1725 1100
Motor Frame Size 48 48 56 48
Filter - Type Disposable Disposable Disposable Disposable
Furnished Yes Yes Yes Yes
(NO.) Size Recommended in. [mm x mm x mm] (2)1x25x16 [25x635x406] (2)1x25x16 [25x635x406] (2)1x25x16 [25x635x406] (2)1x25x16 [25x635x406]
Refrigerant Charge Oz. [g] 195 [5528] 195 [5528] 195 [5528] 195 [5528]
Weights
Net Weight lbs. [kg] 565 [256] 565 [256] 565 [256] 565 [256]
Ship Weight lbs. [kg] 580 [263] 580 [263] 580 [263] 580 [263]
