208-240 VOLT, THREE PHASE, 60 HZ, AUXILLARY ELECTRIC HEATER KITS CHARACTERISTICS AND APPLICATION
Single Power Supply For Both Unit And Heater Kit Separate Power Supply For Both Unit And Heater Kit
Over Current Protective
Device Size
Min/Max @
208 V
Min/Max @
240 V
Min/Max @
208 V
Min/Max @
240 V
No Heat - - - 18/18 25/25 25/25 - - 18/18 25/25 25/25
A06C+ 4.2/5.6 14.33/19.10 11.7/13.5 33/35 35/40 40/40 15/17 15/20 - - -
A10C+ 7.2/9.6 24.56/32.75 20.0/23.1 43/47 45/45 50/50 25/29 25/30 - - -
*A11C+ 7.2/9.6 24.56/32.75 20.0/23.1 43/47 45/45 50/50 25/29 25/30 - - -
A12C+ 8.4/11.2 28.66/38.21 23.4/27.0 48/52 50/50 60/60 30/34 30/35 - - -
A15C+ 10.8/14.4 36.84/49.13 30.1/34.7 56/62 60/60 70/70 38/44 40/45 - - -
A20C+ 14.4/19.2 49.13/65.51 40.1/46.2 69/76 70/70 80/80 50/58 50/60 - - -
*A21C+ 14.4/19.2 49.13/65.51 40.1/46.2 69/76 70/70 80/80 50/58 50/60 - - -
No Heat - - 22/22 30/35 30/35 - - 22/22 30/35 30/35
A06C+ 4.2/5.6 14.33/19.10 11.7/13.5 37/39 40/45 40/45 15/17 15/20 - - -
A10C+ 7.2/9.6 24.56/32.75 20.0/23.1 47/51 50/50 60/60 25/29 25/30 - - -
*A11C+ 7.2/9.6 24.56/32.75 20.0/23.1 47/51 50/50 60/60 25/29 25/30 - - -
A12C+ 8.4/11.2 28.66/38.21 23.4/27.0 52/56 60/60 60/60 30/34 30/35 - - -
A15C+ 10.8/14.4 36.84/49.13 30.1/34.7 60/66 60/60 70/70 38/44 40/45 - - -
A20C+ 14.4/19.2 49.13/65.51 40.1/46.2 72/80 80/80 80/80 50/58 50/60 - - -
*A21C+ 14.4/19.2 49.13/65.51 40.1/46.2 72/80 80/80 80/80 50/58 50/60 - - -
No Heat - - - 23/23 30/35 30/35 - - 23/23 30/35 30/35
A06C+ 4.2/5.6 14.33/19.10 11.7/13.5 37/39 40/45 40/45 15/17 15/20 - - -
A10C+ 7.2/9.6 24.56/32.75 20.0/23.1 48/51 50/50 60/60 25/29 25/30 - - -
*A11C+ 7.2/9.6 24.56/32.75 20.0/23.1 48/51 50/50 60/60 25/29 25/30 - - -
A12C+ 8.4/11.2 28.66/38.21 23.4/27.0 52/56 60/60 60/60 30/34 30/35 - - -
A15C+ 10.8/14.4 36.84/49.13 30.1/34.7 60/66 60/60 70/70 38/44 40/45 - - -
A20C+ 14.4/19.2 49.13/65.51 40.1/46.2 73/80 80/80 80/80 50/58 50/60 - - -
*A21C+ 14.4/19.2 49.13/65.51 40.1/46.2 73/80 80/80 80/80 50/58 50/60 - - -
No Heat - - - 26/26 30/40 30/40 - - 26/26 30/40 30/40
A06C+ 4.2/5.6 14.33/19.10 11.7/13.5 41/43 45/50 45/50 15/17 15/20 - - -
A10C+ 7.2/9.6 24.56/32.75 20.0/23.1 51/55 60/60 60/60 25/29 25/30 - - -
*A11C+ 7.2/9.6 24.56/32.75 20.0/23.1 51/55 60/60 60/60 25/29 25/30 - - -
A12C+ 8.4/11.2 28.66/38.21 23.4/27.0 56/60 60/60 60/60 30/34 30/35 - - -
A15C+ 10.8/14.4 36.84/49.13 30.1/34.7 64/70 70/70 70/70 38/44 40/45 - - -
A20C+ 14.4/19.2 49.13/65.51 40.1/46.2 77/84 80/80 90/90 50/58 50/60 - - -
*A21C+ 14.4/19.2 49.13/65.51 40.1/46.2 77/84 80/80 90/90 50/58 50/60 - - -
Model
No.
RJNL-
RXJJ-
Heater Kit
Nominal kW
Rated Heater
kW @ 208-
240 V
Heater
KBTU/Hr @
208-240 V
A048CM
A060CM
Heat Pump
Min. Ckt.
Ampacity 208
-
240
Heat Pump Over
Current Protective
Device Size
A036CM
A042CM
Heater
Amp. @ 208
-
240 V
Unit Min. Ckt
Ampacity @
208-240 V
Heater Kit
Min. Ckt.
Ampacity
Heater Kit
Max. Fuse
Size
To Next Page
